DI820 3BSE008512R1 S800 I O Modules Digital Input 120V Digital Inputs Module
Product Information Of : DI820 3BSE008512R1
| Brand |
ABB |
| Model |
DI820 |
| ID |
3BSE008512R1 |
| SIZE |
102*119*45mm |
| Weight |
0.3 KG |
Medium Description : Individually galvanic isolated channels.
Use Module Termination Unit TU811, TU813, TU831, TU839, TU851
Catalog Description : DI820 Digital Input 120V a.c. 8 ch
This DI820 module has 8 digital inputs. The a.c. input voltage range is 77 - 130 volt and the input current is 10 mA at 120 V a.c. The d.c. input range is 75 - 145 V and the input current is 2.8 mA at 110 V. The inputs are individually isolated.
Every input channel consists of current limiting components, EMC protection components, input state indication LED, optical isolation barrier and an analog filter (6 ms). Channel 1 can be used as voltage supervision input for channels 2 - 4, and channel 8 can be used as voltage supervision input for channels 5 - 7.
More options:
AI815 Analog Input,1*8 channels, 0..20 mA, 4..20 mA, 0..5V, 1..5 V, HART Interface, Extended Diagnosis
AI820 Analog Input differential, 1*4 channels, -20..20 mA, 0..20 mA, 4..20 mA, -5..5 V, 0..5 V, 1..5 V, -10..10 V, 0..10 V, 2..10 V
AI825 Analog Input 4*1 channels for applications requiring galvanic isolated channels, -20...20 mA, 0(4)...20 mA, -10...10 V, 0(2)...10 V
AI830 Analog Input, 1*8 channels, Resistance Temperature Detector (RTD)
AI835 Analog Input,1*8 channels, Thermocouples (TC)
AI835A Analog Input,1*8 channels, Thermocouples (TC) with remote Cold junction compensation
AI843 Analog Input, 1*8 channels, Thermocouples (TC)
AI845 Analog Input,1*8 channels, 0..20 mA, 4..20 mA, 0..5V, 1..5 V, HART Interface, Extended Diagnosis, Redundant Applications
AI880 High Integrity Analog Input 1*8 channels, 0...20 mA, 4...20 mA
AI890 Analog Input, 1*8 channels, 0..20 mA, 4..20 mA, I.S. Interface
AI893 Analog Input, 1*8 channels, RTD and Thermocouple, I.S Interface
