GE IC200MDL140 8 Individually Isolated Abb Analog Input Module 120 Volts

GE IC200MDL140 8 Individually Isolated Abb Analog Input Module 120 Volts

  • GE IC200MDL140 8 Individually Isolated Abb Analog Input Module 120 Volts
  • GE IC200MDL140 8 Individually Isolated Abb Analog Input Module 120 Volts
GE IC200MDL140 8 Individually Isolated Abb Analog Input Module 120 Volts
Product Details:
Brand Name: GE
Model Number: IC200MDL140
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negitiation
Packaging Details: New in original boxRockwell Automation
Delivery Time: 5-8 work daysRockwell Automation
Payment Terms: T/T
Supply Ability: 1
Contact Now
Detailed Product Description
Condition: New LEDs: Individually Numbered LEDs
Approximate Dimensions: 110 X 66.8 X 50.0 Millimeters Warranty: 1 Year
Location: Versamax I/O Carriers Isolation: Group To Group: 8 Pts: Not Applicable
Series: Versamax Part Number: IC200MDL140
High Light:

GE abb analog input module

,

abb analog input module 120 Volts

,

IC200MDL140

GE IC200MDL140 8 individually-isolated inputs with 120 Volts AC operating voltage


Product information GE IC200MDL140:
These discrete input modules have positive logic or sourcing-type inputs; they receive current from AC input devices and return the current on the common.

Input devices are connected between the input terminals and common terminals. Discrete Input Modules IC200MDL140, IC200MDL141, BXIOIA8120 and BXIOIA8240 provide one group of 8 discrete inputs.

Discrete Input Modules IC200MDL240, IC200MDL241 (shown below), and BXIOIA16120 provide two groups of 8 discrete inputs.



Input power 15-20 Watts per fan
Line Amps 0.24-0.34 Amps per fan
Operating temperature -28 to 70 degrees Celsius
Weight 4 pounds
Filter Polyurethane Foam, 30 PPI
Retainer UL94V-0 Plastic
Compatibility 5-slot series 90-70 racks and the 9-slots RX7i racks


Product Description:
 Input voltage: IC200MDL*40, BXIOIA8120, BXIOIA16120: 0 to 132VAC (47 to 63Hz), 120VAC nominal
                        IC200MDL*41 , BXIOIA8240: 0 to 264VAC (47 to 63Hz), 240VAC nominal

On state voltage: IC200MDL*40, BXIOIA8120, BXIOIA16120: 70 to 132VAC IC200MDL*41, BXIOIA8240: 155 to 264VAC

Off state voltage:IC200MDL*40, BXIOIA8120, BXIOIA16120: 0 to 20VAC IC200MDL*41, BXIOIA8240: 0 to 40VAC

On state current:IC200MDL*40, BXIOIA8120, BXIOIA16120: 5mA minimum IC200MDL*41, BXIOIA8240: 7mA minimum

Off state current: IC200MDL*40, BXIOIA8120, BXIOIA16120: 2.5mA maximum IC200MDL*41, BXIOIA8240: 1.5mA maximum

Input impedance at 60Hz, typical: IC200MDL*40, BXIOIA8120, BXIOIA16120: 8.6kOhms (reactive) IC200MDL*41, BXIOIA8240: 38.5kOhms (reactive) at 60Hz

Input impedance at 50Hz, typical: IC200MDL*40, BXIOIA8120, BXIOIA16120: 10.32kOhms (reactive) IC200MDL*41, BXIOIA8240: 46.3kOhms (reactive) at 50Hz.



Note:
Need carefully inspect all shipping containers for damage. If any equipment is damaged, notify the delivery service immediately.

Save the damaged shipping container for inspection by the delivery service. After unpacking the equipment, record all serial numbers. Save the shipping containers and packing material in case it is necessary to transport or ship any part of the system

Same series:

IC200MDL140A
IC200MDL140D
IC200MDL140H








GE IC200MDL140 8 Individually Isolated Abb Analog Input Module 120 Volts 0
