Product Details:
Place of Origin: France
Brand Name: Schndier
Model Number: 140DDI35300
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negitiation
Packaging Details: in box
Delivery Time: 3-5days
Payment Terms: T/T, Western Union
Supply Ability: 100
Contact Now
Detailed Product Description
Product Name: Modicon Quantum PLC 140DDI35300 Product: Modicon Quantum PLC
Model: 140DDI35300 Brand: Modicon
Group Of Channels: 4 Voltage: 32 /24 V DC
Weight: 0.3 Kg Country Of Origin: France
High Light:

32VDC schneider modicon quantum

,

24vdc schneider modicon quantum

,

140DRA84000

Modicon Quantum PLC 140DRA84000 32 /24 V DC 4 Group of channels





Specifications OF Modicon Quantum PLC 140DDI35300
Group of channels 4
Logic input Negative (source)
Discrete input voltage 24 V DC
Input voltage limits 19.2...30 V
Voltage state 1 guaranteed -30...-15 V DC
Voltage state 0 guaranteed -5...0 V DC
Current state 1 guaranteed >= 2.5 mA at Us = - 14 V
Current state 0 guaranteed <= 0.5 mA
Addressing requirement 2 input words
Input impedance 2400 Ohm
Maximum leakage current 200 mA at Us = 5.5 V and Uin = 4 V
Absolute maximum input 30 V continuous
50 V during 1 ms decaying pulse
Response time <= 1 ms from state 0 to state 1
<= 1 ms from state 1 to state 0
Protection type Input protection by resistor limited
Power dissipation 1.5 W + (0.26 x number of points on)
Isolation between group and bus 1780 Vrms for 1 minute
Isolation between group 500 Vrms for 1 minute
Local signalling 1 LED (green)bus communication is present (Active):
1 LED (red)external fault detected (F)





OTHER SUPERIOR PRODUCTS

Yasakawa Motor, Driver SG- Mitsubishi Motor HC-,HA-
Westinghouse Modules 1C-,5X- Emerson VE-,KJ-
Honeywell TC-,TK- GE Modules IC -
ABB Module AB Module 1756-,1759- Tourch Screen 2711-
Mitsubishi Drive MR- , Motor HA -,HC Emerson MoudlesVE- ,KJ -
Fanuc motor A0-, Drive Yokogawa transmitter EJA-
Rosemount Transmitter 3051- Schneider Module 140-
Panasonic Motor , Drive MH- Siemens Module 6ES-, Touch Screen 6AV-





140DRA84000 32VDC 24vdc Schneider Modicon Quantum 4 Group Channels 0





Frequenty Asked Questions of Modicon Quantum PLC 140DDI35300
What makes Industrial Trading the best source for the SCHNEIDER ELECTRIC 140DDI35300?
Industrial Trading is a service of WTL , an ISO 9001:2015-certified company that specializes in selling parts that are obsolete or hard to find. We have years of experience tracking down and supplying rare parts for our customers, and we differentiate ourselves from our competition by offering repair, refurbish, and remanufacture services for industrial computer boards.


Is the Modicon Quantum PLC 140DDI35300 rare?
Some of the parts on WTL can be very difficult to find. Many are no longer in production and have reached end-of-life status. Once your quote request has been received, WTLwill begin the process of locating for the 140DDI35300. The pricing will be better if no one stirs up the market.


What does "stirring up the market" mean, and why should it be avoided?
Stirring up the market is what happens when many different suppliers are all contacted regarding the same part. It makes other suppliers believe the part is in much higher demand than it might actually be, resulting in raised prices and lower availability. In order to prevent this costly outcome,WTL highly recommends limiting the number of potential suppliers you reach out to for rare parts.


What happens after I receive the quote for the 140DDI35300  ?
Review the quote to make sure it meets your needs. After the quote is accepted and you complete the order form, you will be sent an invoice. It is important that you remit payment immediately after receiving your invoice as any delay could result in the 140DDI35300 being sold to another customer.


What forms of payment are accepted?
We accept all major credit cards (Visa, MasterCard, American Express, and Discover). We also accept wire transfers and PayPal. Checks will only be accepted from customers in the USA. For large orders from repeat customers, terms may be granted pending qualification.


How will the Modicon Quantum PLC 140DRA84000 be shipped to me?
We generally ship via FedEx, UPS, DHL, and USPS, and we are more than happy to use your preferred carrier or account. We do ship to international (non-USA) customers, as well.


What is the estimated lead time for receiving the 140DDI35300 ?
The primary factor in lead time for the 140DDI35300  is availability. If we do not currently have the 140DDI35300 in our inventory, we will check with our trusted suppliers for stock. Services such as repair or refurbishment could affect lead time, as well.
