GE IC697CPU732 CPU MODULE 12MHZ 2K DISCRETE I/O EXPANDABLE MEM FLT PT

GE IC697CPU732 CPU MODULE 12MHZ 2K DISCRETE I/O EXPANDABLE MEM FLT PT

  • GE  IC697CPU732 CPU MODULE 12MHZ 2K DISCRETE I/O EXPANDABLE MEM FLT PT
GE  IC697CPU732 CPU MODULE 12MHZ 2K DISCRETE I/O EXPANDABLE MEM FLT PT
Product Details:
Place of Origin: USA
Brand Name: GE
Model Number: IC697CPU732
Payment & Shipping Terms:
Price: negotiation
Packaging Details: New in original boxRockwell Automation
Delivery Time: 5-8 work daysRockwell Automation
Payment Terms: T/T
Supply Ability: 1
Contact Now
Detailed Product Description
Condition: New Current Required: 1.0 Amp
Voltage Input: 5 Volts DC Warranty: 1 Year
Type Of Memory Storage: 0.2milliseconds Per 1K Of Logic Power Requirements: 67 Milliamps From +5 VDC Supply
User Memory: 240K Bytes Product Type: CPU Module

GE IC697CPU732 CPU MODULE 12MHZ 2K DISCRETE I/O EXPANDABLE MEM FLT PT


Product information GE IC697CPU732:

The IC697CPU732 supports IC697 LAN interface modules, IC697 discrete and analog I/O modules, multiple coprocessor and communications modules, I/O Link Interface modules, and bus controllers for IC66* modules. Configuration of this device is accomplished by connecting the module to a programmer computer and running IC641 programming software.

DIP switches and jumpers are not used in the configuration of this product. For security, configuration settings are password protected. User memory, programming data, the calendar, and the clock are maintained by a lithium CMOS battery.


This device supports an 8-wire serial multidrop configuration. The number of programmable controllers allowed in this configuration is determined by cable length. A 24 AWG 30V serial cable should be used in this setup to connect the controller to a computer. Warning: Terminal strips or alternate connectors should not be used in the transmission line for a multidrop configuration.

To operate the IC697CPU732, use either the three-position switch or an attached computer running IC641 programming software.Refer to the product manual for proper installation instructions. Turn off power before connecting the device. Place the three-position operation switch in the STOP position. Place the battery in one of the battery connection slots. Connect the device to slot 1. Power on the device.


More information:
Configuration The IC697 CPU and I/O system is configured with IC641 programming software. There are no DIP switches or jumpers used to configure the system.

The CPU verifies the actual module and rack configuration at power-up and periodically during operation. The actual configuration must be the same as the programmed configuration. Deviations are reported to the CPU alarm processor function for configured fault response


IC697CPU732 's Features:
 Supports floating point calculations.
 Single slot CPU.
 512 inputs and outputs (any mix).
 Up to 8K analog I/O.  0.4 microseconds per boolean function.
 12 MHz, 80C186 microprocessor.
 Supports IC66* and IC697 I/O.
 Programmed by IC641 software products.
 Configurable data and program memory.
 Battery-backed calendar clock.
 Three position operation mode switch.
 Password controlled access.
 Three status LEDs.


IC697CPU732 's details:
GE  IC697CPU732 CPU MODULE 12MHZ 2K DISCRETE I/O EXPANDABLE MEM FLT PT 0


About  series of  GE 90-70's advantage  :

With our CPX family of CPUs, the Series 90-70 offers more for your automation dollar—more computing power, more memory for your applications, and more communications and redundancy capabilities. And it provides increased flexibility for a variety of applications due to a wide range of isolated and high-density VME analog I/O modules.

Open Architecture Based on the VME-bus standard, the Series 90-70 can be used with thousands of boards produced by hundreds of different manufacturers to build a solution that meets your exact needs. These include links to drives and drive systems, servo motor controllers, embedded solutions for vision systems and bus-to-bus interface modules, as well as a variety of modules available from GE (see accompanying table).




GE  IC697CPU732 CPU MODULE 12MHZ 2K DISCRETE I/O EXPANDABLE MEM FLT PT 1


Our brand:

GE  IC697CPU732 CPU MODULE 12MHZ 2K DISCRETE I/O EXPANDABLE MEM FLT PT 2




Order Process:


1, First, send us the brand, model code/pic of the nameplate, the quantity for inquiry. Then we will send the quote to you. after confirming the model and the quantity, then we will the PI to you.



2, You can transfer by Paypal/ Western Union/Trade assurance/ T/T. When we received the payment, then we will start to prepare the order for you asap.


3, We can according to your shipment to ship out the goods, Or we also can help you to ship out the goods directly. And the tracking number will send you by the next day.

4., Usually for our inventory goods only need to take about 3-5 days.

5. If you also have any questions, you can ask me any time, right below is my contact.
