3BSE020836R1 DI840 Digital Input 24V S/R 16ch ABB Control Systems 800xA I-O Module

 3BSE020836R1 DI840 Digital Input 24V S/R 16ch ABB Control Systems 800xA I-O Module

Product Information Of : 3BSE020836R1 DI840

General info :

Article number : 3BSE020836R1

Catalog Description : DI840 Digital Input 24V S/R 16 ch

Type Designation : DI840

Type : Digital Input

Number of channels : 16

Signal specification : 24V d.c.

HART : No
SOE : Yes

Mechanics : S800

Input impedance : 3.3 kΩ

Filter times (digital, selectable) : 0 to 127 ms

Minimum Order Quantity : 1 piece

Order Multiple : 1 piece

Technical :

1, Channel Type : DI

2, Single or redundant.
3, Advanced On-Board diagnostics.
4, Use Module Termination Unit TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU842, TU843, TU852.

The DI840 is a 16 channel 24 V d.c. digital input module for single or redundant applications. The input voltage range is 18 to 30 V d.c. and the input current is 7 mA at 24 V d.c. Each input channel consists of current limiting components, EMC protection components, input state indication LED and optical isolation barrier.

   The transducer power is supervised and current limited; one output per two input channels. The Sequence of Event function (SOE) can collect events with a resolution of 1 ms. The event queue can contain up to 257 events. The function includes a Shutter filter for filtering out unwanted events.

Features and benefits :

1, 16 channels for 24 V d.c. inputs with current sinking
2, 1 group of 16 isolated from ground
3, Input status indicators
4, Advanced on-board diagnostics
5, Sequence of events
6, Redundant or single applications
7, Transducer power distribution
