Name: New ABB S800 I/O Module 3BSE036634R1 TB825 Multi Mode Modulebus Optical Media Coverter
Brand: Wisdomlong Technology CO.，LTD
SKU: TB825
Price: 1.00 USD
Availability: InStock

Home Products Digital I O Module

New ABB S800 I/O Module 3BSE036634R1 TB825 Multi Mode Modulebus Optical Media Coverter

Product Details:

Brand Name:	ABB
Certification:	CE
Model Number:	TB825

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Contact us
Packaging Details:	New Original Box
Delivery Time:	3-5days
Payment Terms:	T/T
Supply Ability:	50

Contact Now

Detailed Product Description

Model:	TB825	Brand:	ABB
Article Number:	3BSE036634R1	24 V Consumption Typ.:	96 MA
Master Or Slave:	Slave	Protocol:	ABB's Modulebus

New ABB S800 I/O Module 3BSE036634R1 TB825 Multi Mode Modulebus Optical Media Coverter

Description of TB825

S800 I/O is a comprehensive. distributed and modular process I/O system that communicates with parent controllers and PLCs over industry-standard field buses. The TB825 ModuleBus Optical media converter, converts between plastic opto fiber or HCS fiber with versatile link connectors and glass optical fiber with ST connetcors.

The TB825 is built in S800L mechanics and DIN rails mounted. TB825 allows distribution of the optical ModuleBus up to 1000 m per cluster in star configurations.

General Information

Protocol	ABB's Modulebus
Article number	3BSE036634R1
Master or slave	Slave
Line redundancy	No
Module redundancy	No
Hot Swap	No
Used together with HI Controller	Yes

Detailed data

24 V consumption typ. 96 mA

Communications

Model No.	Protocol	Master or slave
CI801	PROFIBUS DP-V1	Slave
CI840A	PROFIBUS DP-V1	Slave
CI853	COMLI and MODBUS RTU	Master / Slave
CI854B	PROFIBUS DP-V1	Master
CI855	ABB's MasterBus 300	Master
CI856	ABB's S100 I/O	Master
CI857	ABB's INSUM	Master
CI858	ABB's DriveBus	Master
CI860	FOUNDATION Fieldbus HSE	Master / Slave
CI865	ABB's Satt I/O	Master
CI867	MODBUS TCP	Master / Slave
CI868	IEC 61850	Master / Slave
CI869	ABB's Advant Fieldbus 100	Slave
CI871	PROFINET IO	Master
CI873	EtherNet IP / DeviceNet	Master
TB820V2	ABB's Modulebus	Slave
TB825 (Multi Mode)	ABB's Modulebus	Slave
TB826 (Single Mode)	ABB's Modulebus	Slave
TB840A	ABB's Modulebus	Slave
TB842	ABB's Modulebus	Not Applicable
TU807	ABB's Modulebus	Not Applicable
TU840	ABB's Modulebus	Not Applicable
TU841	ABB's Modulebus	Not Applicable
TU846	ABB's Modulebus	Not Applicable
TU847	ABB's Modulebus	Not Applicable
TU848	ABB's Modulebus	Not Applicable
TU849	ABB's Modulebus	Not Applicable

Environmental and certification

Temperature, Operating	0 to +55 °C
Temperature, Storage	-25 to +70 °C
Pollution degree	Degree 2, IEC 60664-1
Corrosion protection	ISA-S71.04: G3
Relative humidity	5 to 95 % no condensation
Protection class	IP20 according to EN60529, IEC 529
CE- marking	Yes
Electrical Safety	IEC 61131-2, UL 508
Hazardous location	C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2
Marine certificates	ABS, BV, DNV-GL, LR, RS, CCS
RoHS compliance	EN 50581:2012
WEEE compliance	DIRECTIVE/2012/19/EU

Features and benefits

Converts between plastic or HCS optp fiber and glass optical fiber
DIN rail mounted
Multi Mode functionallity
S800L mechanics

Dimensions

Height	136 mm (5.35 in.) including latch
Width	85.6 mm (3.37 in.)
Depth	58.5 mm (2.30 in.)
Weight (including base)	0.21 kg (0.46 lbs)
