GE IC693MDL260 120 Volts AC and has 32 isolated input points organized in 4 different groups
Product information GE IC693MDL260 :
GE Fanuc IC693MDL260 module is installed in the Series 90-30 PLC system, the operators have control over the input filter times through the DIP switch, which is placed at the back of the module.
It features an LED block on the top of the module for indicating the "ON" and "OFF" status of all 32 points. These indicators are numbered accordingly corresponding to output points 1 to 32. The module also comes with an LED labeled "TB" that indicates when the detachable terminal block is in the right place. When this LED turns red, it means the block has been removed or is not locked in, and in this case, the IC693MDL260 module sends a status message to the RX3i CPU.
However, this message cannot be sent if the module is used with a Series 90-30 CPU. Since there are red bands on the module’s door card, the users can tell that the GE Fanuc IC693MDL260 module is a high-voltage device
Series 90*-30 PLCs
GE Intelligent Platforms’ Series 90*-30 PLCs is a family of controllers, I/O systems and specialty modules designed to meet the demand for versatile industrial solutions — helping businesses gain a sustainable advantage. With its single overall control architecture, the Series 90-30 has been the PLC of record in over 200,000 applications such as highspeed packaging, material handling, complex motion control, water treatment, continuous emissions monitoring, mining, food processing, elevator control, injection molding and many more.
Its modular design offers unique versatility.
Configure just the system you need, saving critical space and reducing cost. With over 100 I/O modules, the Series 90-30 PLC can be adapted to a wide range of applications.
• Digital interfaces for push buttons, switches, proximity sensors, relays, contactors and many other devices
• Analog modules with varying degrees of resolution for flow, temperature or pressure applications
• Direct connect wiring or remote termination
• Local or remote I/O systems
More information:
| CPU Type |
5-slot baseplate with embedded CPU |
| Total Baseplates per System |
1 |
| Load Required from Power Supply |
410 milliamps from +5 VDC supply |
| Processor Speed |
10 MegaHertz |
| Processor Type |
80188 |
| Operating Temperature |
0 to 60 degrees C (32 to 140 degrees F) ambient |
| Typical Scan Rate |
18 milliseconds per 1K of logic (boolean contacts) |
| User Program Memory (maximum) |
6K Bytes |
|
Discrete Input Points - %I
Discrete Output Points - %Q
|
160 (maximum - combined inputs + outputs)
160 (maximum - combined outputs + inputs)
|
| Discrete Global Memory - %G |
1280 bits |
| Internal Coils - %M |
1024 bits |
| Output (Temporary) Coils - %T |
256 bits |
| System Status References - %S |
128 bits (%S, %SA, %SB, %SC - 32 bits each) |
| Register Memory - %R |
512 words |
| Analog Inputs - %AI |
64 words |
| Analog Outputs - %AQ |
32 words |
| System Registers (for reference table viewing only; cannot be referenced in user logic program) |
16 words (%SR) |
| Timers/Counters |
170 |
| Shift Registers |
yes |
| Built-in Serial Ports |
1 (uses connector on PLC power supply). Supports SNP slave and SNP-X slave protocols. |
| Communications |
LAN - Supports multidrop. Also supports Ethernet, FIP, Profibus, GBC, GCM, GCM+ option modules. |
| Override |
no |
| Battery Backed Clock |
no |
| Interrupts |
no |
| Type of Memory Storage |
RAM and optional EPROM or EEPROM |
| PCM/CCM Compatibility |
no
|
Another module:
| IC694MDL230 |
120 VAC Isolated Input (8 Points) |
| IC694MDL231 |
240 VAC Isolated Input (8 Points) |
| IC694MDL240 |
120 VAC Input (16 Points) |
| IC694MDL241 |
24 VAC/VDC Input (16 Points) |
| IC694MDL250 |
120 VAC Isolated Input (16 Points) |
| IC694MDL260 |
120 VAC Input (32 Points)** |
| IC694MDL632 |
125 VDC Input (8 Points) |
| IC694MDL634 |
24 VDC Input, Neg/Pos Logic (8 Points) |
| IC694MDL645 |
24 VDC Input, Neg/Pos Logic (16 Points) |
| IC694MDL646 |
24 VDC Input, Neg/Pos Logic, 1 msec Filter (16 Points) |
| IC694MDL654 |
5/12 VDC (TTL) Input, Neg/Pos Logic, (32 Points) |
| IC694MDL655 |
24 VDC Input, Neg/Pos Logic, 1 ms, (32 Points) |
| IC694MDL660 |
24 VDC Input (32 Points)** |
| IC694ACC300 |
Input Simulator Module (8 Points) |
