1746-P3 allen bradley io module Rockwell Automation 0 To 60 Degrees Celsius SLC 500 Power Supply

1746-P3 AB Rockwell Automation 0 to 60 degrees Celsius SLC 500 Power Supply

Technical Specifications for 1746-P3
Manufacturer Rockwell Automation
Part Number/Catalog No. 1746-P3
Isolation Voltage 600V ac RMS for 1 s (version B or later)
Inrush Current 20 A
Typical line power requirement 90 VA
Nom Input Voltage 24VDC
Current Capacity 3.6 A at 5V dc and 0.87 A at 24V dc
Brand AB
Hold Up time 5 ms (full load); 1000 ms (no load)
Fuse protection 1746-F3 or equivalent
Temperature, ambient operating 0...60 °C (32...140 °F)
Series SLC 500
Module Type Power Supply
Input Voltage Range 19.2-28.8 VDC
Location 1746 Chassis, Left Side
Current capacity deration 5% above 55 °C (131 °F).
Input Voltage 24 Volts DC
Input Power 61 Watts
Backplane Current (5 Volts) 3.6 Amps
Backplane Current (24 Volts) 0.87 Amps
Frequency DC
Weight 2.5 pounds (1.1 kilograms)
Dimensions 5.5 x 2.9 x 5.7 inches
Operating Temperature 0 to 60 degrees Celsius
Dimensions 5.5 x 2.9 x 5.7 inches
Operating Temperature 0 to 60 degrees Celsius
UPC 10662073521430
