Product information GE IC694CHS398 :

The GE Fanuc Series 90-30 Programmable Logic Controller (PLC) module with catalog number IC693ALG223 is a Sixteen (16) channels, single ended, analog input module that is used to interface field devices and instrument that provide analog signals as representation to measurement of process variable.

Specifically, each channel of the IC693ALG223 is configurable of receiving 0-20 mA, 4-20 mA and 4-20 mA enhanced signals. Some of the devices that are capable of providing these signals are Transmitters, Variable Frequency Drive’s (VFD) speed feedback, data loggers, panel meters and other devices.

PACSystems RX3i Features:
• High-speed processor and patented technology for faster throughput without information bottlenecks
• Dual backplane bus support per module slot:
- High-speed, PCI-based for fast through put of new advanced I/O
- Serial backplane for easy migration of existing Series 90-30 I/O
• Multiple CPU offerings meeting various performance criteria up to and includ-ing an Intel ® 1 GHz CPU for advanced programming and performance with 64 Mbytes memory
• Memory for ladder logic documentation and machine documentation (Word, Excel, PDF, CAD and other files) in the controller to reduce downtime and improve troubleshooting

• Open communications support including Ethernet, GENIUS*, Profibus ™ , HART, DeviceNet ™ and serial
• Supports high density discrete I/O, univer-sal analog (TC, RTD, Strain Gauge, Voltage and Current configurable per channel), isolated analog, high-density analog,high-speed counter, and motion modules
• Expanded I/O offering with extended features for faster processing, advanced diagnostics and a variety of configurable interrupts
• Hot insertion for both new and migrated modules

High Performance Control on One Platform:
The PACSystems RX3i provides logic, motion,HMI, and process control with open commu-nications protocols.
• PACMotion modules can control up to 40 high speed axes in one rack
• PACSystems High Availability solution offers true dual redundancy data synchronization and bumpless transfer
• The Control Memory Xchange offers amaz-ing data transfer at a rate of 2.12 Gbaud

Universal Development Environment:
The common software platform across all GE controllers, award-winning Proficy* Machine Edition* software provides the universal engineering development environment for programming, configuration and diagnostics for the entire PACSystems family.
• Programming tools such as tag-based programming, a library of reusable code and a test edit mode for improved online troubleshooting
• User-friendly environment that can increase design flexibility and improve engineering efficiency and productivity
