GE IC200MDL643 24 Volts DC rated positive/negative logic input module which has 16 input points

GE IC200MDL643 24 Volts DC rated positive/negative logic input module which has 16 input points

Product information GE IC200MDL643 :

The IC200MDL643 Discrete Input Module has 1.45 milliamps of minimum on-state current and 0 to 0.7 milliamps of minimum off-state current. The on and off response time is 0.25 milliseconds maximum. It also offers 3 configurable input filter times to compensate in noise spikes and switch bounces that are 0.25 milliseconds, 1.25 milliseconds, and 7.25 milliseconds. The 2 input groups have a common connection point. A group can be wired for either positive or negative logic.

A shorting bar with 2 Amps of current-carrying capacity is available to use with the B Terminal in case the system needs additional bussed terminals. The IC200MDL643 Discrete Input Module comes with 0 to 15 Volts DC of input voltage and 1.8 milliamps of user input current at 5 Volts DC and it has 4.9 milliamps of current at 12 Volts DC. It has no thermal derating and no external power supply. During installation, make sure that the hot insertion is done properly to avoid backplane disruption.

The GE Fanuc Series 90-30 Programmable Logic Controller (PLC) module with catalog number IC693ALG223 is a Sixteen (16) channels, single ended, analog input module that is used to interface field devices and instrument that provide analog signals as representation to measurement of process variable.
