CI512-ETHCAT ABB Brand New Digital I O Communication Module 24V

CI512-ETHCAT ABB Brand New Digital I O Communication Module 24V

Description:

Extended Product Type: CI512-ETHCAT
Product ID: 1SAP221000R0001
ABB Type Designation: CI512-ETHCAT
EAN: 4016779664837

Catalog Description: Interface module. EtherCAT slave. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. 8 configurable DI/DO: 24VDC 0.5A. Cam switch functionality (CI512-ETHCAT)

Long Description: CI512-ETHCAT: S500 Interface module. EtherCAT slave. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. 8 configurable DI/DO: 24VDC 0.5A. Cam switch functionality. Extendable by up to 10 I/O modules.

CN8: 85389091
Invoice Description: Interface module. EtherCAT slave. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. 8 configurable DI/DO: 24VDC 0.5A. Cam switch functionality (CI512-ETHCAT)
Made To Order: No

Minimum Order Quantity: 1 piece
Order Multiple: 1 piece
Selling Unit of Measure: piece

Dimensions

Product Net Weight: 0.138 kg
Product Net Depth / Length: 62 mm
Product Net Height: 76 mm
Product Net Width: 67.5 mm
Gross Weight: 0.162 kg

Package Level 1 Depth / Length: 84 mm
Package Level 1 Height: 72 mm
Package Level 1 Width: 71 mm
Package Level 1 Units: 1 carton

Technical Function: EtherCAT slave. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. 8 configurable DI/DO: 24VDC 0.5A. Cam switch functionality

Number of Hardware Interfaces: Industrial Ethernet 2

Other 0
Parallel 0
RS-232 0
RS-422 0
RS-485 0
Serial TTY 0
USB 0

Wireless 0
Analog Inputs: 0
Analog Outputs: 0

Number of Digital Inputs: 8
Number of Digital Outputs: 8
Number of Digital Configurable I/Os: 8
Input Voltage Type: DC

Input Voltage (Uin): 24 V DC
Input Current: 5 mA
Delay Time (τ): 0.1 … 32 ms
Output: Transistor

Output Voltage Type: DC
Output Current: 0.5 A

Output Voltage Maximum: 20.4 … 28.8 V
Degree of Protection: IP20
Supply Voltage: 20.4 ... 28.8 V DC

Additional Information
Product Main Type: CI512
Product Name: Distributed Automation I/Os
Classifications eClass: 27-24-26-07

ETIM 8: EC001604 - Fieldbus, decentr. periphery - communication module
UNSPSC: 32151705
