ABB OTM160E4CM230C 1SCA022848R1510 MOTORIZED C/O SWITCH, Direct Mounted Handle, Open Transition

ABB OTM160E4CM230C 1SCA022848R1510 MOTORIZED C/O SWITCH, Direct mounted handle, Open transition


General Information

Ordering
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85365080
Country of Origin:
Finland (FI)



Dimensions
Product Net Width:
307 mm
Product Net Height:
150 mm
Product Net Depth / Length:
197 mm
Product Net Weight:
6.2 kg
13.7 lb



Technical
Rated Operational Current AC-21A (Ie):
(380 ... 415 V) 160 A
(500 V) 160 A
(690 V) 160 A
Rated Operational Current AC-22A (Ie):
(380 ... 415 V) 160 A
(500 V) 160 A
(690 V) 160 A
Rated Operational Current AC-23A (Ie):
(380 ... 415 V) 160 A
(500 V) 160 A
(690 V) 160 A
Rated Operational Current AC-31B (Ie):
(380 ... 415 V) 160 A
Rated Operational Current AC-33B (Ie):
(380 ... 415 V) 160 A
Rated Operational Power AC-23A (Pe):
(380 ... 415 V) 90 kW
(500 V) 110 kW
(690 V) 160 kW
Conventional Free-air Thermal Current (Ith):
Θ = 40 °C 160 A
Conventional Thermal Current (Ithe):
Fully Enclosed 160 A
Rated Impulse Withstand Voltage (Uimp):
12 kV
Rated Insulation Voltage (Ui):
1000 V
Rated Operational Voltage:
1000 V
Rated Short-time Withstand Current Low Voltage (Icw):
for 1 s 8 kiloampere rms
Motor Operational Voltage:
220 ... 240 V AC
Power Loss:
2.4 W
Pollution Degree:
3
Handle Color:
Black
Handle Type:
Direct mounted handle
Fourth Pole Position:
Right Side
Fourth Pole Type:
Switched - Simultaneous Function
Switches Operating Mechanism:
Mechanism at the End of the Switch
Distance Between Phases:
Standard
Position of Line Terminals:
Top In - Bottom Out, Bottom In - Top Out
Operating Mode:
Front operated
Mounting Type:
Base mounting
Number of Poles:
4
Degree of Protection:
Front IP20
Transition Type:
Open


Technical UL/CSA

Wire Stripping Length:
7 mm
Recommended Screw Driver:
Main Circuit Pozidriv 2
Tightening Torque:
Main Circuit 1.2 N·m

Environmental

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Environmental Information:
1SCC303036D0202


Container Information
Package Level 1 Units:
1 piece
Package Level 1 Width:
215 mm
Package Level 1 Depth / Length:
395 mm
Package Level 1 Height:
215 mm
Package Level 1 Gross Weight:
7.6 kg
Package Level 1 EAN:
6417019298696


Classifications

Object Classification Code:
Q
ETIM 7:
EC000216 - Switch disconnector
ETIM 8:
EC000216 - Switch disconnector
ETIM 9:
EC000216 - Switch disconnector (low voltage)
UNSPSC:
39122233
IDEA Granular Category Code (IGCC):
5290 >> Disconnect switch
eClass:
V11.1 : 27371403
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
E-Number (Finland):
3641704
