3BSE069209R1 TU818 ABB Brand Compact Module Termination Unit
Description:
Product Type: Module_Termination_Unit
Product ID: 3BSE069209R1
ABB Type Designation: TU818
Catalog Description: TU818 Compact MTU, 50V
Long Description: Compact Module Termination Unit with 1x32 (and 2x16) signal terminals.
Ordering
HS Code: 853690-- Electrical apparatus for switching or protecting electrical circuits, or for making connections to or in electrical circuits (for example, switches, relays, fuses, surge suppressors, plugs, sockets, lamp-holders and other connectors, junction boxes), for a voltage not exceeding 1,000 volts; connectors for optical fibres, optical fibre bundles or cables.- Other apparatus
Customs Tariff Number: 85369095
Dimensions
Product Net Depth / Length: 64 mm
Product Net Height: 170 mm
Product Net Width: 58.5 mm
Product Net Weight: 0.26 kg
Environmental
RoHS Status: Following EU Directive 2011/65/EU
WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
Number of Batteries: 0
SCIP: No SVHC present Bulgaria (BG)
The TU818 is a 32 channel 50 V compact module termination unit (MTU) for the S800 I/O. The MTU is a passive unit used for connection of the field wiring to the I/O modules. It also contains a part of the ModuleBus.
The MTU distributes the ModuleBus to the I/O module and to the next MTU. It also generates the correct address to the I/O module by shifting the outgoing position signals to the next MTU.
Two mechanical keys are used to configure the MTU for different types of I/O modules. This is only a mechanical configuration and it does not affect the functionality of the MTU or the I/O module. Each key has six positions, which gives a total number of 36 different configurations.
Features and benefits
- Compact installation of I/O modules using one-wire or two-wire (depends on I/O module type) connections.
- Up to 32 channels of field signals and process power connections.
- Connections to ModuleBus and I/O modules.
- Mechanical keying prevents insertion of the wrong I/O module.
- Latching device to DIN rail for grounding.
- DIN rail mounting.
General Information
| Article number |
3BSE069209R1 |
| Type |
Compact |
| Connection |
Terminal block |
| Channels |
32 |
| Voltage |
50 V |
| Mounting |
Both directions |
| Mounting detail |
Horizontal 55 ºC (131 °F)
Vertical 40 ºC (104 °F) |
| Use with I/O |
AI810, AI815, AI835A, AI843, AI845, AI880A, DI810, DI811, DI818, DI830, DI831, DI840, DI880, DI885, DO818, DP840 |
| Process connections |
40 pole screw terminal |
| Single/redundant I/O |
Single |
Detailed data
| Maximum current per I/O channel |
2.5 A |
| Maximum current process connection |
L1+ max 8A L2+ max 8A |
| Acceptable wire sizes |
Solid: 0.5 - 2.5 mm2
Stranded: 0.5 - 1.5 mm2 |
| Dielectric test voltage |
500 V a.c. |
I/O MTU TERMINAL UNIT
| Name |
Type |
Connection |
Channels |
Voltage |
Mounting |
| TU810V1 |
Compact |
Terminal block |
16 |
50 V |
Both directions |
| TU811V1 |
Compact |
Terminal block |
8 |
250 V |
Both directions |
| TU812V1 |
Compact |
25 pin D-sub |
16 |
50 V |
Both directions |
| TU813 |
Compact |
Crimp Snap-in connector |
8 |
250 V |
Both directions |
| TU814V1 |
Compact |
Crimp Snap-in connector |
16 |
50 V |
Both directions |
| TU818 |
Compact |
Terminal block |
32 |
50 V |
Both directions |
| TU819 |
Compact |
25 pin D-sub |
32 |
50 V |
Both directions |
| TU830V1 |
Extended |
Terminal block |
16 |
50 V |
Both directions |
| TU831V1 |
Extended |
Terminal block |
8 |
250 V |
Both directions |
| TU833 |
Extended |
Crimp Snap-in connector |
16 |
50 V |
Both directions |
| TU834 |
Extended |
Terminal block |
8 |
50 V |
Both directions |
| TU835V1 |
Extended |
Terminal block |
8 |
50 V |
Both directions |
| TU836V1 |
Extended |
Terminal block |
8 |
250 V |
Both directions |
| TU837V1 |
Extended |
Terminal block |
8 |
250 V |
Both directions |
| TU838 |
Extended |
Terminal block |
16 |
50 V |
Both directions |
| TU839 |
Extended |
Terminal block |
8 |
250 V |
Both directions |
| TU842 |
Redundant |
Terminal block |
16 |
50 V |
Horizontal |
| TU843 |
Redundant |
Terminal block |
16 |
50 V |
Vertical |
| TU844 |
Redundant |
Terminal block |
8 |
50 V |
Horizontal |
| TU845 |
Redundant |
Terminal block |
8 |
50 V |
Vertical |
| TU850 |
Extended |
Terminal block |
16 |
50 V |
Both directions |
| TU851 |
Extended |
Terminal block |
16 |
250 V |
Both directions |
| TU852 |
Redundant |
25 pin D-sub |
16 |
50 V |
Horizontal |
| TU854 |
Redundant |
25 pin D-sub |
16 |
50 V |
Horizontal |
| TU890 |
Compact |
Terminal block |
8 |
24 V |
Horizontal |
| TU891 |
Compact |
Terminal block |
8 |
24 V |
Horizontal |
Environmental and certification
| CE mark |
Yes |
| Electrical safety |
IEC 61131-2 |
| Hazardous Location |
ATEX Zone 2 |
| Marine certification |
ABS, BV, DNV-GL, LR, RS |
| Protection rating |
IP20 according to IEC 60529 |
| Corrosive atmosphere ISA-S71.04 |
G3 |
| Climatic operating conditions |
0 to +55 °C (Storage -40 to +70 °C), RH=5 to 95 % no condensation, IEC/EN 61131-2 |
| Pollution degree |
Degree 2, IEC 60664-1 |
| Mechanical operating conditions |
IEC/EN 61131-2 |
| EMC |
EN 61000-6-4, EN 61000-6-2 |
| Overvoltage categories |
IEC/EN 60664-1, EN 50178 |
| Equipment class |
Class I according to IEC 61140; (earth protected) |
| RoHS compliance |
EN 50581:2012 |
| WEEE compliance |
DIRECTIVE/2012/19/EU |
