MITSUBISHI MELSERVO INDUSTRIAL AC SERVO DRIVE 400W MR-J3-40B New Amplifier in stock

MITSUBISHI MELSERVO INDUSTRIAL AC SERVO DRIVE 400W MR-J3-40B New Amplifier in stock

  • MITSUBISHI MELSERVO INDUSTRIAL AC SERVO DRIVE 400W MR-J3-40B New Amplifier in stock
  • MITSUBISHI MELSERVO INDUSTRIAL AC SERVO DRIVE 400W MR-J3-40B New Amplifier in stock
MITSUBISHI MELSERVO INDUSTRIAL AC SERVO DRIVE 400W MR-J3-40B New Amplifier in stock
Product Details:
Place of Origin: Japan
Brand Name: Mitsubishi
Certification: CE
Model Number: MR-J3-40B
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Contact us
Packaging Details: New Original Box
Delivery Time: 3-5days
Payment Terms: T/T
Supply Ability: 50
Contact Now
Detailed Product Description
Model: MR-J3-40B Brand: Mitsubishi
Type: AC Servo Product Name: Servo Amplifier
Power: 400W MOQ: 1pcs

MITSUBISHI MELSERVO INDUSTRIAL AC SERVO DRIVE 400W MR-J3-40B New Amplifier in stock



MITSUBISHI MR-J3-40B 400W AC SERVO DRIVER

(Specifications taken from manual)

Input Voltage/frequency: 1-phase 100-120VAC, 50/60Hz
Permissible voltage fluctuation: 172-253VAC
Output: 200V
Control System: Sine-wave PWM control/current control system
Position control mode
Maximum input pulse frequency: 1000kpps (when using differential receiver), 200kpps (when using open collector)
Speed control mode
Speed control range: analog speed command 1:2000, internal speed command 1:5000
Torque control mode
Torque command input: 0-±8V DC maximum torque (input impedance 10-12kOhm)
encoder resolution: 262144 pulses per rev.
Position and Speed Control: Analog inputs and pulse train interface
Output Power: 400W
Mass: 1.0kg

(If you need further data, please search Google or similar, since it's no longer allowed to put links to manuals here.)
This Servo Driver - MR-J3-40B - is to be used with HF-MP43*, HF-KP43* Servo Motors.



The following functions of the MR-J3-40B (GA) model is deleted:
Master-slave operation
Encoder Z-phase pulse output




The following functions of the MR-J3-40B (GA) model is changed:
CN1A/CN1B is always lit. (Note 2)
(Same while the cable and the cap are used.)





Description of Mitsubishi AC Servo Amplifier



  • High-speed controllers for ultra-short positioning times; average speed frequency response 2100Hz
  • High-resolution encoders for maximum speed constancy (18 bits 262,144 P/rev)
  • Advanced vibration suppression for outstanding adaptation to machine requirements
  • Auto tuning for extremely fast setup and installation
  • Optimum cost/benefit ratio
  • Absolute position encoder included as standard equipment
  • Minimum wiring overheads thanks to Plug & Play configuration and automatic motor identification
  • Supports global standards
  • Shipping Weight: 2.5 kg

We specialize in selling and servicing a wide range of Mitsubishi products and components:
  • MDS and MR Series AC Servo Drives
  • MDS and FR Series AC Spindle Drives
  • FR Series General Purpose Inverters and Braking Modules
  • HA / HC / HF / HP / HS Series AC Servo Motors
  • SJ Series AC Spindle Motors
  • CNC Boards
  • Power Supplies



Similiar Models:





MR-J3-10A
MR-J3-10B
MR-J3-10T
MR-J3-20A
MR-J3-20B
MR-J3-20T
MR-J3-40A
MR-J3-40B
MR-J3-40T
MR-J3-60A
MR-J3-60B
MR-J3-60T
MR-J3-70A
MR-J3-70B
MR-J3-70T
MR-J3-100A
MR-J3-100B
MR-J3-100T
MR-J3-200A
MR-J3-200B
MR-J3-200T
MR-J3-350A
MR-J3-350B
MR-J3-350T
MR-J3-500A
MR-J3-500B
MR-J3-500T
MR-J3-700A
MR-J3-700B
MR-J3-700T




Mitsubishi Servo Motors

HC-MFS053 HC-KFS053 HC-MFS13 HC-KFS13 HC-MFS053B HC-KFS053B
HC-MFS13B HC-KFS13B HC-MFS053K HC-KFS053K HC-MFS13K HC-KFS13K
HC-MFS053BK HC-KFS053BK HC-MFS13BK HC-KFS13BK HC-MFS23 HC-KFS23
HC-MFS43 HC-KFS43 HC-MFS23B HC-KFS23B HC-MFS43B HC-KFS43B
HC-MFS23K HC-KFS23K HC-MFS43K HC-KFS43K HC-MFS23BK HC-KFS23BK
HC-MFS43BK HC-KFS43BK HC-MFS73 HC-KFS73 HC-MFS73B HC-KFS73B
HC-MFS73K HC-KFS73K HC-MFS73BK HC-KFS73BK HC-SFS81 HC-SFS121
HC-SFS201 HC-SFS301 HC-SFS52 HC-SFS102 HC-SFS152 HC-SFS202
HC-SFS52B HC-SFS102B HC-SFS152B HC-SFS202B HC-SFS52K HC-SFS102K
HC-SFS152K HC-SFS202K HC-SFS52BK HC-SFS102BK HC-SFS152BK HC-SFS202BK
HC-SFS352 HC-SFS502 HC-SFS702 HC-SFS352B HC-SFS502B HC-SFS702B
HC-SFS353 HC-SFS352K HC-SFS502K HC-SFS702K HC-RFS353 HC-RFS103
HC-RFS153 HC-RFS203 HC-RFS353 HC-SFS53 HC-SFS103 HC-SFS153
HC-SFS203 HC-KFS13 HC-KFS13B HC-MF73-S15 HC-MF053 HC-KFSP3





What is Details of Our Mitsubishi Parts?

  • All the Mitsubishi Parts are new and original with package.
  • Warranty time: 1 year.

Company Introduction
MITSUBISHI MELSERVO INDUSTRIAL AC SERVO DRIVE 400W MR-J3-40B New Amplifier in stock 0


Good Service in WTL:

> We offer high quality, fast delivery, competitive price for Mitsubishi Servo Drives and Motors.

> Please send your RFQ to get the latest price.

> Normally, we will ship the items in 1-2 weeks after receive the payment.

> We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways.

> We have a large stock and the prices are variable, so sometimes the prices we post are not accurate. If needed, please contact us for specific prices.




Liability:



WTL is not liable for any personal injury or property damage resulting from the use of this equipment. It is

buyer's responsibility as to the safe handling & operation of this equipment and to verify equipment is

compliance to their machinery.
