SGMAH-01AAA2C AC Servo Motor Yaskawa AC Servo Motor 220V 3000r/min 0.91A

SGMAH-01AAA2C AC Servo Motor Yaskawa AC Servo Motor 220V 3000r/min 0.91A

  • SGMAH-01AAA2C AC Servo Motor Yaskawa AC Servo Motor  220V 3000r/min 0.91A
  • SGMAH-01AAA2C AC Servo Motor Yaskawa AC Servo Motor  220V 3000r/min 0.91A
  • SGMAH-01AAA2C AC Servo Motor Yaskawa AC Servo Motor  220V 3000r/min 0.91A
SGMAH-01AAA2C AC Servo Motor Yaskawa AC Servo Motor  220V 3000r/min 0.91A
Product Details:
Place of Origin: Japan
Brand Name: Yaskawa
Model Number: SGM-01V314
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negitiation
Payment Terms: T/T, Western Union,
Contact Now
Detailed Product Description
Product Name: Industrial Servo Motors SGMAH-01AAA2C Product: Industrial Servo Motors
Model: SGMAH-01AAA2C Brand: Yaskawa
POWER SUPPLY: 200V Power: 100W
PHASE: 0.91A Country Of Origin: Japan

SGMAH-01AAA2C AC Servo Motor Yaskawa AC Servo Motor 220V 3000r/min 100w







Quick Details

  • AC Voltage : 220V

  • Application : CNC

  • Brand Name : YASKAWA

  • Certification : CE, ROHS, UL

  • Efficiency : IE 2

  • Current:0.91A

  • Model Number : SGSGMAH-01AAA2C

  • Ins : B

  • Place of Origin : Japan

  • Power : 100w

  • power supply : AC

  • Protect Feature : Drip-proof

  • protect feature : Drip proof

  • Speed : 3000r/min

  • Type : Servo Motor

  • type : with brake

  • voltage : 200V







OTHER SUPERIOR PRODUCTS

Yasakawa Motor, Driver SG- Mitsubishi Motor HC-,HA-
Westinghouse Modules 1C-,5X- Emerson VE-,KJ-
Honeywell TC-,TK- GE Modules IC -
ABB Module AB Module 1756-,1759- Tourch Screen 2711-
Mitsubishi Drive MR- , Motor HA -,HC Emerson MoudlesVE- ,KJ -
Fanuc motor A0-, Drive Yokogawa transmitter EJA-
Rosemount Transmitter 3051- Schneider Module 140-
Panasonic Motor , Drive MH- Siemens Module 6ES-, Touch Screen 6AV-



SGMAH-01AAA2C AC Servo Motor Yaskawa AC Servo Motor  220V 3000r/min 0.91A 0



SGM - 01 A 3 1 2 j Σ-Series Servomotor SGM: SGM Servomotor SGMP: SGMP Servomotor (cube type) Rated Output (Motor Capacity) Model SGM Only A3: 30 W A5: 50 W SGM and SGMP 01: 100 W 02: 200 W 03: 300 W 04: 400 W 08: 750 W Supply Voltage A: 200 V B: 100 V Options B: With brake (90 V) C: With brake (24 V) D: With brake (90 V) and shaft seal E: With brake (24 V) and shaft seal P: Drip-proof S: With shaft seal Shaft Specifications 2: Straight without key 4: Straight with key 6: Straight with key and tap Design Revision Order Encoder Specifications 3: 2048 P/R incremental encoder W: 12-bit absolute encoder Not Standard 5: 2000 P/R incremental encode





The size of the allowable load moment of inertia of a servomotor depends on the capacity, and is limited to 5 to 30 times the motor inertia. This value is provided strictly as a guideline and results may vary depending on servomotor drive conditions. An overvoltage alarm is likely to occur during deceleration if the load moment of inertia exceeds the allowable load moment of inertia. SERVOPACKs with a built-in regenerative resistor may generate a regeneration overload alarm. Take one of the following steps if this occurs.





Reduce the torque limit.



• Reduce the deceleration rate.

• Reduce the maximum motor speed.

• Install an externally mounted regenerative resistor if the alarm cannot be cleared. Contact your Yaskawa Application Engineering Department.





Regenerative resistors are not built into 200 V for 50 W to 400 W and 100 V for 50 W to 400 W SERVOPACKs. The following figures show the tentative relationship between the load moment of inertia and motor speed using an example with a load moment of inertia 10 to 30 times the load moment of inertia at the motor shaft. External regenerative resistors are required when this condition is exceeded or if the allowable loss capacity (W) of the built-in regenerative resistor is exceeded due to regenerative drive conditions when a regenerative resistor is already built in.
