GYB401D5-RC2-B Industrial Servo Motor Fuji Electric Electric Systems 3-phase 200V

GYB401D5-RC2-B Industrial Servo Motor Fuji Electric Electric Systems 3-phase 200V

  • GYB401D5-RC2-B Industrial Servo Motor Fuji Electric Electric Systems 3-phase 200V
  • GYB401D5-RC2-B Industrial Servo Motor Fuji Electric Electric Systems 3-phase 200V
GYB401D5-RC2-B Industrial Servo Motor Fuji Electric Electric Systems 3-phase 200V
Product Details:
Place of Origin: Japan
Brand Name: Fuji Electric
Certification: CE
Model Number: GYB401D5-RC2-B
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiated
Packaging Details: New Original
Delivery Time: 5-8days
Payment Terms: T/T
Supply Ability: 1000
Contact Now
Detailed Product Description
Brand: Fuji Electric Type: GYB401D5-RC2-B
Part Number: GYB401D5-RC2-B Power: 200w
Phase: 3 Phase Frequency: 50/60Hz

GYB401D5-RC2-B Industrial Servo Motor Fuji Electric Electric Systems 3-phase 200V













Product Description of GYB401D5-RC2-B



  • Product No : GYB401D5-RC2-B

  • Product Ttype : Middle Inertia GYB Servo Motor

  • GYB : Middle Inertia Type

  • Rated Output : 401 = 40×101 = 400W

  • Rated Speed : D = 3000r/min series

  • Development Order : 5 = 5

  • Encoder : R = INC(20bit)

  • Oil seal/shaft : C = Without oil seal, straight shaft, with key, tapped

  • Input voltage : 2 = 3-phase 200V

  • Brake: B= With









Trade Information of GYB401D5-RC2-B







Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal

100 Piece Per Day

1 Days

Yes

Contact us for information regarding our sample policy

AS PER CUSTOMER

Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

All India

FUJI GYB401D5-RC2-B











Standard specifications





Motor type
(-B) indicates the brake-incorporated type.
GYB201D5-□□2 (-B) GYB401D5-□□2 (-B) GYB751D5-□□2 (-B)
Rated output [kW] 0.2 0.4 0.75
Rated torque [N.m] 0.637 1.27 2.39
Rated speed [r/min] 3000
Max. speed [r/min] 6000*1
Max. torque [N.m] 1.91 3.82 7.17
Inertia [kg.m2]
( ) indicates brake-incorporated type.
0.24×10-4
(0.29×10-4)
0.42×10-4
(0.46×10-4)
1.43×10-4
(1.61×10-4)
Rated current [A] 1.5 2.7 5.2
Max. current [A] 4.5 8.1 15.6
Winding insulation class Class B
Degree of enclosure protection Totally enclosed, self-cooled (IP 67. excluding the shaft-through)*2
Terminals (motor) 0.3m cable
Terminals (encoder) 0.3m cable
Overheat protection Not provided (The servo amplifier detects temperature.)
Mounting method By securing motor flange IMB5 (L51), IMV1 (L52), IMV3 (L53)
Encoder 18-bit serial encoder (absolute/incremental), 20-bit serial encoder (incremental)
Vibration level*3 V5 or below
Installation place, altitude and environment For indoor use (free from direct sunlight), 1000m or below, locations without corrosive and flamable gases, oil mist and dust
Ambient temperature, humidity -10 to +40°C, within 90% RH (without condensation)
Vibration resistance [m/s2] 49
Mass [kg]
( ) indicates brake-incorporated type.
1.0
(1.5)
1.5
(2.1)
3.0
(3.9)
Compliance with standards UL/cUL (UL508c) (Some models are in the process to be certified), CE marking (low power directive EN61800-5-1), RoHS directive.















FUJI Servo Drive



Fuji Electric is one of the Japanese heavy motor manufacturers that mainly produces large electrical machines.

Fuji ALPHA7 servo amplifiers include the following types,
•High-speed serial bus VS type/LS type
•General-purpose interface VV type
•Open Network VC type

The popular long-running Fuji FALDIC series servo amplifiers, like FALDIC-α series, have been discontinued. The ALPHA 7 series servo amplifiers can be purchased as replacement models for future equipment upgrades or new applications.
