140CPU43412A Modicon Quantum PLC / CPU Single Slot 80486 Processor With Mathematical

Product Details:

Place of Origin:	France
Brand Name:	Schneider
Certification:	CE
Model Number:	140CPU43412A

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD
Packaging Details:	new original box
Delivery Time:	3-5days
Payment Terms:	T/T, Union,payoneer
Supply Ability:	50 pcc/week

Contact Now

Detailed Product Description

Brand:	Schneider	Model:	140CPU43412A
Type:	Modicon Quantum Automation Platform	Country Of Origin:	France
Condition:	New Original	Deliver:	3-5days
MOQ:	1 PCS	Warranty:	1 Year

140CPU43412A Factory New SEALED Modicon Quantum CPU 140-CPU-434-12A

Quick details:

SCHNEIDER ELECTRIC
MODICON
140-CPU-434-12A
140CPU43412A
CPU MODULE 2MB SRAM 2X MODBUS 1X MODBUS PLUS
AVAILABLE
New one with one year warranty and used one with six months warranty
Weight: 2.00lbs

More Info on the 140CPU43412A:

Quantum | 140CPU43412A | Modicon | 140 CPU 434 12A | Processor 486K RAM 2MEG 2xMB, 1xMB

The Quantum 140CPU43412A CPU is a single-slot programmable controller with built-in executive memory, application memory andcommunication ports. All memory components are on board so noadditional chips or cartridges are necessary.Quantum CPUs use flash memory technology to support the CPU’sexecutive memory and instruction set. Flash is a state-of-the-art,nonvolatile memory technology that enables downloadable fieldupgrades as new features become available.The application program can be stored in either battery-backed RAMand/or Flash RAM. The battery is located on the front of the CPU andcan be serviced while the CPU is running. To protect the applicationprogram from inadvertent changes during operation, the140CPU43412A features a memory-protect switch. An LED goes onwhen this switch is activated.The 140CPU43412A CPU has two Modbus® ports and one ModbusPlus™ port. Simple rotary switches on the back of the CPU are used toset the network address of the Modbus Plus port. Each device on aModbus Plus network must have a unique address in the range 1 … 64.

**Complementary:**
clock frequency	66 MHz
memory description	Internal RAM 896 kB
exact time for 1 Kinstruction	0.1...0.5 ms LL984
watchdog timer	250 ms
clock drift	+/-8 s/day at 32...140 °F (0...60 °C)
I/O words	30 I/32 O distributed 64 I/64 O max local 64 I/64 O remote
I/O words/network	500 I/500 O distributed
drops/network	63 distributed
number of drops	31 remote
number of network	2 remote 3 distributed
battery type	Lithium 7 µA 210 µA
battery capacity	1.2 Ah
battery life	10 yr
number of port	1 Modbus Plus 2 Modbus RS232
communication module processor capacity	6 NOM, NOE, CR, NMS
switch function	Key switch
marking	CE
bus current requirement	1250 mA
module format	Standard
product weight	1.87 lb(US) (0.85 kg)

**Environment:**
product certifications	FM Class 1 Division 2 CUL
standards	CSA C22.2 No 142 UL 508
resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields	9.14 V/yd (10 V/m) 80...2000 MHz conforming to IEC 801-3
ambient air temperature for operation	32...140 °F (0...60 °C)
ambient air temperature for storage	-40...185 °F (-40...85 °C)
relative humidity	95 % without condensation
operating altitude	<= 16404.2 ft (5000 m)

Technical FAQs:

What is the replacement for the 140CPU43412A?
The replacement is the 140CPU43412U.
Which Quantum PLCs allow the use of an Aux task in Unity?

The 140CPU65150, 140CPU65160, and 140CPU67160 allow the use of Aux tasks numbered 0 thru 3. The 140CPU31110, 140CPU43412A, and 140CPU53414A will only allow the use of a Fast and a Mast task.

Legacy KB System (APS) Data: RESL2568 V1.0, Originally authored by on , Last Edited by on
Related ranges:

AEDL3
Which Quantum PLCs have the Factory Mutual (FM) Class 1 Div. 2 rating?

All Quantum CPUs are FM Class 1 Div 2 approved.
140CPU11302
140CPU11303
140CPU43412A
140CPU53414A
140CPU53414B
140CPU65150
140CPU65160
140CPU652 60
140CPU67160
140CPU67260
140CPU67261
140CPU65160S (SIL 3 / ATEX Zone 2/22) This CPU meets and exceeds the FM Class 1 Div. 2 rating
140CPU67160S (SIL 3 / ATEX Zone 2/22) This CPU meets and exceeds the FM Class 1 Div. 2 rating

..

Legacy KB System (APS) Data: RESL210922 V1.0, Originally authored by DaSo on 03/09/2013, Last Edited by DaSo on 03/09/2013
Related ranges: Modicon Quantum
Dimensions of Modules and Racks:

140CPU43412A Modicon Quantum PLC / CPU Single Slot 80486 Processor With Mathematical 0

(1) 2 slots
(2) 3 slots
(3) 4 slots
(4) 6 slots
(5) 10 slots
(6) 16 slots

Terms:

We ships worldwide and accepts T/T and Paypal.

All items are subject to availability and passing our QA testing and inspection.

Turnaround Time:

Standard order processing is 1-2 business days plus shipping method chosen.

Rush and off-hours service available for an additional fee

Packaging and Handling:

Items are safely packaged in custom shipping cartons for protection.

Shipping:

We ship worldwid use UPS, FedEx, DHL, or Truck Freight when needed.

Call to use a shipping service other than the ones listed.

International Customers are responsible for all Customs fees, VAT, and other fees applied by their

respective countries.

All shipments are fully insured.
