Name: 6SL3210-1KE23-8UF1 SIEMENS SINAMICS G120C RATED POWER 18,5KW WITH 150% OVERLOAD
Brand: Wisdomlong Technology CO.，LTD
SKU: 6SL3210-1KE23-8UF1
Price: 1.00 USD
Availability: InStock

Home Products Variable Frequency Inverter

6SL3210-1KE23-8UF1 SIEMENS SINAMICS G120C RATED POWER 18,5KW WITH 150% OVERLOAD

Product Details:

Place of Origin:	GERMANY
Brand Name:	Siemens
Certification:	CE
Model Number:	6SL3210-1KE23-8UF1

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Contact us
Packaging Details:	New Original Box
Delivery Time:	3-5days
Payment Terms:	T/T
Supply Ability:	50

Contact Now

Detailed Product Description

Model:	6SL3210-1KE23-8UF1	Brand:	Siemens
Net Weight:	5.2KG	Type:	Inverter
Rated Power (LO):	18.50 KW	Rated Power (HO):	15.00 KW

6SL3210-1KE23-8UF1 SIEMENS SINAMICS G120C RATED POWER 18,5KW WITH 150% OVERLOAD

Product Description

SINAMICS G120C RATED POWER 18,5KW WITH 150% OVERLOAD FOR 3 SEC 3AC380-480V +10/-20% 47-63HZ UNFILTERED I/O-INTERFACE: 6DI, 2DO,1AI,1AO SAFE TORQUE OFF INTEGRATED FIELDBUS: PROFINET-PN PROTECTION: IP20/ UL OPEN TYPE SIZE: FSC 295x 140x 225,4 (HXWXD) EXTERNAL 24V

Rated data

Input

Number of phases	3 AC
Line voltage	380 ... 480 V +10 % -20 %
Line frequency	47 ... 63 Hz
Rated current (LO)	48.20 A
Rated current (HO)	45.20 A

Output

Number of phases	3 AC
Rated voltage	400V IEC	480V NEC 1)
Rated power (LO)	18.50 kW	25.00 hp
Rated power (HO)	15.00 kW	20.00 hp
Rated current (LO)	37.00 A
Rated current (HO)	Rated current (HO)	31.00 A
Rated current (IN)	38.00 A
Max. output current	62.00 A
Pulse frequency	4 kHz
Output frequency for vector contro	0 ... 240 Hz
Output frequency for V/f control	0 ... 550 Hz

Closed-loop control techniques

V/f linear / square-law / parameterizable Yes

V/f with flux current control (FCC)

Yes

V/f ECO linear / square-law

Yes

Sensorless vector control

Yes

Vector control, with sensor

Encoderless torque control

Torque control, with encoder

We also can offer these Models:

Brand	Model	Codition
Siemens	6SL3 224-0BE15-5UA0	NEW
Siemens	6SL3 224-0BE17-5UA0	NEW
Siemens	6SL3 224-0BE21-1UA0	NEW
Siemens	6SL3 224-0BE21-5UA0	NEW
Siemens	6SL3 224-0BE22-2AA0	NEW
Siemens	6SL3 224-0BE22-2UA0	NEW
Siemens	6SL3 224-0BE23-0UA0	NEW
Siemens	6SL3 224-0BE24-0AA0	NEW
Siemens	6SL3 224-0BE24-0UA0	NEW
Siemens	6SL3 224-0BE25-5AA0	NEW
Siemens	6SL3 224-0BE27-5AA0	NEW
Siemens	6SL3 224-0BE27-5UA0	NEW
Siemens	6SL3 224-0BE31-1AA0	NEW
Siemens	6SL3 224-0BE31-1UA0	NEW
Siemens	6SL3 225-0BE32-2AA0	NEW
Siemens	6SL3 225-0BE33-0AA0	NEW
Siemens	6SL3 244-0BB12-1BA1	NEW
Siemens	6SL3 244-0BB12-1FA0	NEW
Siemens	6SL3 244-0BB12-1PA1	NEW
Siemens	6SL3 224-0BE31-5AA0	NEW
Siemens	6SL3 224-0BE31-5UA0	NEW
Siemens	6SL3 224-0BE31-8AA0	NEW
Siemens	6SL3 224-0BE32-2AA0	NEW
Siemens	6SL3 224-0BE33-0AA0	NEW
Siemens	6SL3 224-0BE33-0UA0	NEW
Siemens	6SL3 224-0BE33-7UA0	NEW
Siemens	6SL3 224-0BE34-5UA0	NEW
Siemens	6SL3 224-0BE35-5UA0	NEW
Siemens	6SL3 224-0BE37-5UA0	NEW

Liability:

WTL is not liable for any personal injury or property damage resulting from the use of this equipment. It is
buyer's responsibility as to the safe handling & operation of this equipment and to verify equipment is
compliance to their machinery.
