PLC Programmable Logic Controller MITSUBISHI MELSEC Q PLC CPU Q00CPU PLC Programmable Logic Controller
| Operating ambient temperature |
0 to 55 ° C |
| Storage ambient temperature |
-25 to 75 ° C |
| Ambient humidity |
5 to 95% RH, non condensing |
| Storage ambient humidity |
5 to 95% RH, non condensing |
| Internal relay [M] |
default 8192 points (M 0 to 8191) (changeable) |
| Latch relay [L] |
default 2048 points (L 0 to 2047) (changeable) |
| Link relay [B] |
default 2048 points (B 0 to 7 FF) (changeable) |
Specifications:
| Attribute |
Value |
| For Use With |
MELSEC Q Series |
| Number of I/O |
2048 |
| Manufacturer Series |
MELSEC Q |
| Input Type |
Analogue, Digital |
| Voltage Category |
5 V dc |
| Output Type |
Analogue, Digital |
| Communication Port Type |
RS232C |
| Program Capacity |
32 kB |
| Programming Interface |
Computer, Operating Panel |
| Length |
89.3mm |
| Maximum Inputs/Outputs |
8192 |
| Number of Communication Ports |
1 |
| Width |
27.4mm |
| Maximum Operating Temperature |
+55°C |
| Dimensions |
89.3 x 27.4 x 98 mm |
| Depth |
98mm |
| Battery Backup |
Yes |
| Minimum Operating Temperature |
0°C |
| Mounting Type |
DIN Rail |
| Memory |
94 kB |
Impact resistance Meets JIS B 3502, IEC 61131-2 (147 m / s 2, 3 times in each of X, Y and Z directions)
Operating atmosphere No corrosive gas
Usage Altitude 0 to 2000 m
Installation location in control panel
Over voltage category Ⅱ or less
Pollution degree 2 or less
Device class Class I
Special relay [SM] 1024 points (SM 0 to 1023) (Device number is fixed)
Special register [SD] 1024 points (SD 0 to 1023) (Device number is fixed)
Function input [FX] 16 points (FX 0 to F) (Device number is fixed)
Function output [FY] 16 points (FY 0 to F) (the number of device points is fixed)
Function register [FD] 5 points (FD 0 to 4) (Device number is fixed)
Height (H) 98 mm
Width (W) 27.4 mm
Depth (D) 89.3 mm
Data register [D] default 11136 points (D0 to 11135) (changeable)
Link register [W] default 2048 points (W 0 to 7 FF) (changeable)
Annunciator [F] default 1024 points (F0 to 1023) (changeable)
Edge relay [V] default 1024 points (V 0 to 1023) (changeable)
Similer item we can supply:
-Q01CPU -Q02(H)CPU -Q06HCPU -Q12HCPU -Q25HCPU -Q02PHCPU -Q06PHCPU -Q12PHCPU -Q25PHCPU -Q00UCPU -Q01UCPU -Q02UCPU -Q03UDVCPU -Q03UD(E)CPU -Q04UDVCPU -Q04UD(E)HCPU -Q06UDVCPU -Q06UD(E)HCPU -Q10UD(E)HCPU -Q13UDVCPU -Q13UD(E)HCPU -Q20UD(E)HCPU -Q26UDVCPU -Q26UD(E)HCPU -Q50UDEHCPU
