Product Description

General Electric Multilin’s UR-67H is a Digital Input/Output communications module with 8 Form-A outputs. The digital I/O modules generally offer up to 96 contact inputs and up to 64 contact outputs; these inputs/outputs can be configured to manage and monitor a large swath of equipment installed in the given power system. The auxiliary equipment can communicate with the relay, which processes the signals and produces useable data that the relay can employ in its protection and control functions.

Prospective buyers should refer to the user manual appropriate to their unit in order to understand what modules their relay came with and which they did not. Any order code with an “XX” indicates that it did not come with that module; if power system demands increase or users determine post-purchase that a particular module would be helpful, it is especially pertinent that prospective buyers track that model down.

General Electric Multilin’s UR-67H contacts do not include monitoring or latching functions, so users should ensure these features are not needed before purchasing this particular module. Mechanically latching outputs can be employed to create secure interlocking applications and also remove the need for certain auxiliary equipment; prospective buyers seeking these features can reference the UR user manuals for more information about the parts that do contain these elements.

Frequently Asked Questions about UR-67H

How do I determine which universal relays could contain the UR-67H digital I/O module?

The digital I/O module option 67 is found in a variety of different ordering breakdowns. For example, the B30 bus differential system is a cost-effective option to provide bus differential protection for up to six feeder systems. The B30 is able to meter voltage, current, and frequency. The variable digital outputs that are possible with the B30 bus differential relay are the trip rated Form-A Form-C, or Solid State Relay mechanical latching digital outputs. The SSR and Form-A options can also have current detection or circuit continuity monitoring. The function of the mechanical latch output is to replace a lockout relay by forming a secure interlocking application of the relay. With consideration of the B30 product feature description as specified and with consultation of the ordering codes in the B30 model number breakdown, one is able to predict which digital I/O module options may be contained in the universal B30 relay. Thus every B30 relay will not have the exact same digital I/O card and according features. The B30 ordering chart contains up to 20 different possibilities for the digital I/O, and even has an order code (XX) for a lack of a digital I/O module. One would need to consider each ordering code breakdown for the 20 universal relays to determine which of the 20 contain the digital I/O 67 option.

Features:

• 8 Form-A digital outputs
• High-current rating (12 A)
• Wide operating temperature range (-40°C to +70°C)
• Compact design (140 mm x 100 mm x 36 mm)

Specification

• Manufacturer: GE Multilin
• Product No.: UR-67H
• Product Type: Digital I/O Module
• Number of digital outputs: 8
• Output type: Form-A
• Output current rating: 12 A
• Output voltage rating: 240 V AC/DC
• Operating temperature range: -40°C to +70°C (-40°F to +158°F)
• Storage temperature range: -40°C to +85°C (-40°F to +185°F)
