Name: Mitsubishi HCKFS73BK AC Servo Motor Electric Servo Motor
Brand: Wisdomlong Technology CO.，LTD
SKU: HC-MFS/KFS73BK
Price: 1.00 USD
Availability: InStock

Home Products AC Servo Amplifier

Mitsubishi HCKFS73BK AC Servo Motor Electric Servo Motor

Product Details:

Place of Origin:	Japan
Brand Name:	Mitsubishi
Certification:	CE
Model Number:	HC-MFS/KFS73BK

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiated
Packaging Details:	New Original
Delivery Time:	3-5days
Payment Terms:	L/C, T/T
Supply Ability:	1000

Contact Now

Detailed Product Description

Brand:	Mitsubishi	Product Type:	Industrial Servo Drives
Part Number:	HC-MFS/KFS73BK	Place Of Origin:	Japan
Frequency:	200-230 VAC	Power:	200W
Highlight:	Electric Servo Motor , Mitsubishi AC Servo Motor , HCKFS73BK AC Servo Motor

Mitsubishi HCKFS73BK AC Servo Motor Electric Servo Motor

Product Descriptions of HCKFS73BK

The Mitsubishi Electric HC-KFS73BK is a high-performance AC servo motor designed for various industrial applications. This motor is designed to be efficient and reliable, and it is part of the MELSERVO series. The HC-KFS73BK motor is an AC brushless rotary servo motor with a shaft that has a keyway and a key. The motor also has a built-in electromagnetic brake and an absolute feedback encoder/position detector with a 17-bit resolution for providing it with precise positioning and control capabilities. The motor has low inertia ratings and a small power capacity rating. To ensure efficient operation and temperature control, the HC-KFS73BK incorporates fan cooling. It is part of the 200V voltage class and has a rated current of 5.8A. The HC-KFS73BK servo motor’s rated output power is 750W (0.75kW), and it supports a rated speed of 3000 rpm, and a maximum speed of 4500 rpm. The HC-KFS73BK motor operates with a nominal torque rating of 2.4 Nm and a maximum torque rating of 7.2 Nm. The motor measures approximately 98.1 mm x 82 mm x 217.5 mm, and it can be mounted with an 80 x 80 mm flange. Its enclosure has an ingress protection rating of IP55, and this enclosure protects the motor from dust and water. It should be noted that the enclosure does not provide an IP55 degree of protection to the motor’s connector section or shaft-through portion. The HC-KFS73BK servo motor is suitable for operation in ambient temperatures ranging from 0 to 40 degrees Celsius, and it can be safely stored at ambient temperatures between -15 and 70 degrees Celsius.

The HC-KFS73BK servo motor is an AC rotary servo motor that was manufactured by Mitsubishi Electric as part of the MELSERVO product line. It has an output power rating of 750W (0.75kW), and it is a low-inertia and small-capacity type of servo motor. The HC-KFS73BK servo motor’s rated current is 5.8A, and its maximum current rating is 18.6A. The HC-KFS73BK servo motor has a built-in feedback encoder that is rated at 131,072 pulses per revolution (PPR). This encoder supports speed and position detection to ensure efficient performance in demanding tasks. The HC-KFS73BK servo motor can support a rated torque of 2.4 Nm and a maximum torque rating of 7.2 Nm. Additionally, its rated speed is 3000 RPM, its maximum speed rating is 4500 RPM, and its instantaneous permissible speed rating is 5175 RPM. The HC-KFS73BK servo motor supports an 80 x 80mm flange mounting option for easy integration into various systems, and it supports flexibility in system design. The HC-KFS73BK servo motor’s structure is a self-cooled structure that is completely enclosed. Moreover, the HC-KFS73BK servo motor’s IP55 protection rating ensures that is protected from moderate amounts of dust and water in a variety of industrial environments. The HC-KFS73BK servo motor is engineered for an operating temperature range from 0°C to +40°C. In addition, the HC-KFS73BK servo motor comes with a shaft that has a keyway and a key. It also comes with a built-in electromagnetic brake. The HC-KFS73BK servo motor’s keyed shaft facilitates secure coupling with other system components, while the electromagnetic brake provides it with braking and deceleration capabilities.

Technical Specifications for HC-KFS73BK

Motor Type:	AC brushless rotary servo motor
Motor Series:	MELSERVO
Shaft Design:	Keyed shaft
Brake Type:	Built-in electromagnetic brake
Encoder Type:	Absolute feedback encoder
Encoder Resolution:	17-bit, 131072 pulses/rev
Inertia:	Low inertia
Power Capacity:	Small power capacity
Voltage Class:	200V
Rated Power:	750W (0.75kW)
Rated Speed:	3000 RPM

Models of Mitsubishi drive

Servo amplifier	Servo motor with functional safety
MR-J4-10GF-RJ MR-J4-10B-RJ MR-J4-10A-RJ	HG-KR053(B)W0C, 13(B)W0C
MR-J4-20GF-RJ MR-J4-20B-RJ MR-J4-20A-RJ	HG-KR23(B)W0C
MR-J4-40GF-RJ MR-J4-40B-RJ MR-J4-40A-RJ	HG-KR43(B)W0C
MR-J4-60GF-RJ MR-J4-60B-RJ MR-J4-60A-RJ	HG-SR51(B)W0C, 52(B)W0C HG-JR53(B)W0C.
MR-J4-70GF-RJ MR-J4-70B-RJ MR-J4-70A-RJ	HG-KR73(B)W0C HG-JR73(B)W0C
MR-J4-100GF-RJ MR-J4-100B-RJ MR-J4-100A-RJ	HG-SR81(B)W0C, 102(B)W0C HG-JR53(B)W0C (Note 1, 3), 103(B)W0C
MR-J4-200GF-RJ MR-J4-200B-RJ MR-J4-200A-RJ	HG-SR121(B)W0C, 201(B)W0C, 152(B)W0C, 202(B)W0C HG-JR73(B)W0C (Note 1, 3), 103(B)W0C (Note 1, 3), 153(B)W0C, 203(B)W0C
MR-J4-350GF-RJ MR-J4-350B-RJ MR-J4-350A-RJ	HG-SR301(B)W0C, 352(B)W0C HG-JR153(B)W0C (Note 1), 203(B)W0C (Note 1), 353(B)W0C
MR-J4-500GF-RJ MR-J4-500B-RJ MR-J4-500A-RJ	HG-SR421(B)W0C, 502(B)W0C HG-JR353(B)W0C (Note 1), 503(B)W0C
MR-J4-700GF-RJ MR-J4-700B-RJ MR-J4-700A-RJ	HG-SR702(B)W0C HG-JR503(B)W0C (Note 1), 703(B)W0C, 701M(B)W0C
MR-J4-11KGF-RJ MR-J4-11KB-RJ MR-J4-11KA-RJ	HG-JR903(B)W0C, 11K1M(B)W0C
MR-J4-15KGF-RJ MR-J4-15KB-RJ MR-J4-15KA-RJ	HG-JR15K1M(B)W0C
MR-J4-22KGF-RJ MR-J4-22KB-RJ MR-J4-22KA-RJ	HG-JR22K1MW0C

MDS series Servo Drive

MDS-D-V1-20	MDS-D-V1-40	MDS-D-V1-80	MDS-D-V1-160	MDS-D-V1-160W
MDS-D-V1-320W	MDS-D-V2-2020	MDS-D-V2-4020	MDS-D-V2-4040	MDS-D-V2-8040
MDS-D-V1-320	MDS-D-V2-8080	MDSD-V2-16080	MDS-D-V2-160160	MDS-D-V2-160160W
MDS-DM-V3-202020	MDS-DM-V3-404040	MDS-D-SP-20	MDS-D-SP-40	MDS-D-SP-80
MDS-D-SP-160	MDS-D-SP-200	MDS-D-SP-240	MDS-D-SP-320	MDS-D-SP-400
MDS-D-SP-640	MDS-D-SP2-2020	MDS-D-SP2-4020	MDS-D-SP2-4040S	MDS-D-SP2-8040
MDS-D-SP2-8080	MDS-D-SP2-16080S	MDS-D-CV-37	MDS-D-CV-75	MDS-D-CV-110
MDS-D-CV-185	MDS-D-CV-300	MDS-D-CV-370	MDS-D-CV-450	MDS-D-CV-550

Models of Mitsubishi AC SERVO MOTOR

HF-MP053	HF-MP13	HF-MP13	HF-MP23	HF-MP43
HF-MP73	HF-KP053	HF-KP13	HF-KP23	HF-KP43
HF-KP73	HF-MP053B	HF-MP13B	HF-MP23B	HF-MP43B
HF-MP73B	HF-KP053B	HF-KP13B	HF-KP23B	HF-KP43B
HF-KP73B	HF-SP52	HF-SP102	HF-SP152	HF-SP202
HF-SP352	HF-SP502	HF-SP702	HF-SP52B	HF-SP102B
HF-SP152B	HF-SP202B	HF-SP352B	HF-SP502B	HF-SP702B
HF-SP51	HF-SP81	HF-SP121	HF-SP201	HF-SP51B
HF-SP81B	HF-SP121B	HF-SP201B	HG-SR352BK	HG-SR352BJ

Similer item we can supply:

MR-J2S-10B-S149	MR-J2S-20B-S149	MR-J2S-40B-EE085
MR-J2S-40B-EE006	MR-J2S-40B-S009U528	MR-J2S-40CP-S186
MR-J2S-40CP-S084	MR-J2S-40A-PY091	MR-J2S-40B-PY096
MR-J2S-40B-PY135	MR-J2S-40B-S210	MR-J2S-40A-PF
NR-J2S-60A-PF	MR-J2S-40A-PQ108T022	MR-J2S-40B-PY096T018
MR-J2S-60B-S041U638	MR-J2S-60B-S134	MR-J2S-40B-PY135
MR-J2S-60B-FH168	MR-J2S-40B1-EH018	MR-J2S-40B1-QA112
MR-J2S-40CP1	MR-J2S-60B-S030	MR-J2S-40B-QT0009U625
MR-J2S-40CP-EG	MR-J2S-10CP1	MR-J2S-40A-S004
MR-J2S-20CP1	MR-J2S-10A1-S017	MR-J2S-70A-S011
MR-J2S-20A-S011	MR-J2S-40A-S011	MR-J2S-100A-S011
MR-J2S-40A-EG055	MR-J2S-40A-EG011	MR-J2S-20CP-S011
MR-J2S-70CP-S011	MR-J2S-200B-S126	MR-J2S-70CP-S259
MR-J2S-70B-T004	MR-J2S-350CP-S186	MDS-B-SVJ2-07
MR-J2S-70B-RT	MR-J2S-350CP-S084	MDS-D-SVJ3-01NA
MR-J2S-100B-T004	MR-J2S-350B-EG	MDS-D-SVJ3-02NA
MR-J2S-100B-RT	MR-J2S-350B-EG117	MDS-D-SVJ3-07NA
MR-J2S-70A-PM070	MDS-B-SVJ2-01	MDS-D-SVJ3-10NA
MR-J2S-200A-EJ012	MDS-B-SVJ2-03	MDS-D-SVJ3-20NA
MR-J2S-200B-T004	MDS-B-SVJ2-04	MR-J2S-100CP-S084
MR-J2S-200A-S007	MDS-B-SVJ2-06	MR-J2S-100CP-S186
MR-J2S-200B-S009V613	MDS-B-SVJ2-10	MR-J2S-70B-PY135U504
MR-J2S-200B-RS238	MDS-B-SVJ2-20	MR-J2S-40B-PY135U504

Warranty

We offer 1 year warranty for this product. If the product is out of working order under proper usage per

instructions manual within the warranty period, please contact us to obtain a merchandise return code and

shipping instruction. Then, send it back at your shipping costs.

After receiving your return item, it will take 7 days for evaluation and investigation. A brand new

replacement unit will be sent to you at our shipping costs if it meets our warranty requirements.

Payment

Credit card on line is available.We also accept payment by T/T and Western Union.
This item have stock,so can delivery to you within 3 business days after your payment cleared.If ther

is any import duties or taxes,it is the buyer's responsibility.

Good Service in WTL:
> We offer high quality, fast delivery, competitive price for Mitsubishi Servo Motor and Servo Drive.
> Please send your RFQ to get the latest price.
> Normally, we will ship the items in 1-2 weeks after receive the payment.
> We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways.
> We have a large stock and the prices are variable, so sometimes the prices we post are not accurate.

If needed, please contact us for specific prices.v
