CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100

CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100

  • CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100
  • CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100
CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100
Product Details:
Place of Origin: Japan
Brand Name: Mitsubishi
Certification: CE
Model Number: HF-KN73J-S100
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Contact us
Packaging Details: New Original Box
Delivery Time: 3-5days
Payment Terms: T/T,
Supply Ability: 50
Contact Now
Detailed Product Description
Model: HF-KN73J-S100 Brand: Mitsubishi
Series: HF-KN Series Rated Output Power: 750W
Rated Speed: 3000r/ Min Rating Current: 4.8A


CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100

Models of HF-KN73 Series Servo motors


Mitsubishi HF-KN73
Output :0.75 KW
Maximum torque :7.2 Nm
Rated Speed :3000 1/min
Max speed :4500 1/min
Rotor inertia Standard:0.000143-0.000163 kg.m²
Rated Current :4.8 A
Max. Current :14 A
Weight Standard:3.1-4.1 Kg


Mitsubishi HF-KN73K
Output :0.75 KW
Maximum torque :7.2 Nm
Rated Speed :3000 1/min
Max speed :4500 1/min
Rotor inertia Standard:0.000143-0.000163 kg.m²
Rated Current :4.8 A
Max. Current :14 A
Weight Standard:3.1-4.1 Kg



Mitsubishi HF-KN73J
Output :0.75 KW
Maximum torque :7.2 Nm
Rated Speed :3000 1/min
Max speed :4500 1/min
Rotor inertia Standard:0.000143-0.000163 kg.m²
Rated Current :4.8 A
Max. Current :14 A
Weight Standard:3.1-4.1 Kg



Mitsubishi HF-KN73B
Output :0.75 KW
Maximum torque :7.2 Nm
Rated Speed :3000 1/min
Max speed :4500 1/min
Rotor inertia Standard:0.000143-0.000163 kg.m²
Rated Current :4.8 A
Max. Current :14 A
Weight Standard:3.1-4.1 Kg



Mitsubishi HF-KN73BK
Output :0.75 KW
Maximum torque :7.2 Nm
Rated Speed :3000 1/min
Max speed :4500 1/min
Rotor inertia Standard:0.000143-0.000163 kg.m²
Rated Current :4.8 A
Max. Current :14 A



Mitsubishi HF-KN73BJ
Output :0.75 KW
Maximum torque :7.2 Nm
Rated Speed :3000 1/min
Max speed :4500 1/min
Rotor inertia Standard:0.000143-0.000163 kg.m²
Rated Current :4.8 A
Max. Current :14 A
Weight Standard:3.1-4.1 Kg



Mitsubishi HF-KN73BJK
Output :0.75 KW
Maximum torque :7.2 Nm
Rated Speed :3000 1/min
Max speed :4500 1/min
Rotor inertia Standard:0.000143-0.000163 kg.m²
Rated Current :4.8 A
Max. Current :14 A
Weight Standard:3.1-4.1 Kg



Model designation

CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100 0


Specifications


Output0.75 KW
Maximum torque7.2 Nm
Rated Speed3000 1/min
Max speed4500 1/min
Rotor inertia0.000143-0.000163 kg.m²
Rated Current4.8 A
Max. Current14 A
Weight3.1-4.1 Kg
Rated Torque2.4 Nm


Models of HF-KN Series I ndustrial Servo Motors


0.1KWHF-KN13J-S1000.5KWHF-SN52J-S100
 MR-JE-10A MR-JE-70A
 MR-ECN1 MR-ECN1
 MR-J3ENCBL5M-A1-L MR-J3ENSCBL5M-L
 MR-PWS1CBL5M-A1-L MR-PWCNS4
 MR-ECNP1-B MR-ECNP1-B
 MR-ECNP2-B MR-ECNP2-B
0.2KWHF-KN23J-S1001KWHF-SN102J-S100
 MR-JE-20A MR-JE-100A
 MR-ECN1 MR-ECN1
 MR-J3ENCBL5M-A1-L MR-J3ENSCBL5M-L
 MR-PWS1CBL5M-A1-L MR-PWCNS4
 MR-ECNP1-B MR-ECNP1-B
 MR-ECNP2-B MR-ECNP2-B
0.4KWHF-KN43J-S1001.5KWHF-SN152J-S100
 MR-JE-40A MR-JE-200A
 MR-ECN1 MR-ECN1
 MR-J3ENCBL5M-A1-L MR-J3ENSCBL5M-L
 MR-PWS1CBL5M-A1-L MR-PWCNS4
 MR-ECNP1-B MR-ECNP1-B1
 MR-ECNP2-B MR-ECNP2-B1
0.75KWHF-KN73J-S1002KWHF-SN202J-S100
 MR-JE-70A MR-JE-200A
 MR-ECN1 MR-ECN1
 MR-J3ENCBL5M-A1-L MR-J3ENSCBL5M-L
 MR-PWS1CBL5M-A1-L MR-PWCNS5
 MR-ECNP1-B MR-ECNP1-B1
 MR-ECNP2-B MR-ECNP2-B1


Models of HF-KN Series Servo motors
HF-KN13
HF-KN13B
HF-KN13J
HF-KN13J-S100
HF-KN13BJ-S100
HF-KN23
HF-KN23B
HF-KN23J
HF-KN23J-S100
HF-KN23BJ-S100
HF-KN43
HF-KN43B
HF-KN43J
HF-KN43J-S100
HF-KN43BJ-S100
HF-KN73
HF-KN73B
HF-KN73J
HF-KN73J-S100
HF-KN73BJ-S100





Rating Plate

CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100 1

Parts identification
CE 0.75kw 14A 3000r/ Min MITSUBISHI Servo Motor HF-KN73J-S100 2






Good Service in WTL:
> We offer high quality, fast delivery, competitive price for Mitsubishi Servo Motor.
> Please send your RFQ to get the latest price.
> Normally, we will ship the items in 1-2 weeks after receive the payment.
> We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways.
> We have a large stock and the prices are variable, so sometimes the prices we post are not accurate. If needed, please contact us for specific prices.



Liability:


WTL is not liable for any personal injury or property damage resulting from the use of this equipment. It is
buyer's responsibility as to the safe handling & operation of this equipment and to verify equipment is
compliance to their machinery.
