Place of Origin: | Japan |
Brand Name: | OMRON |
Model Number: | R7D-BPA5L |
Minimum Order Quantity: | 1 |
---|---|
Price: | 1 |
Packaging Details: | New in original boxRockwell Automation |
Delivery Time: | 5-8 work daysRockwell Automation |
Payment Terms: | T/T |
Supply Ability: | 1 |
Condition: | New | Rated Torque: | 1.3 Nm |
---|---|---|---|
Peak Torque: | 3.65 Nm | Warranty: | 1 Year |
Encoder Resolution: | 200 W | Flange Size Square (LC): | 80 Mm |
Shaft Diameter: | 14 Mm | Drive Supply Voltage: | Servo AC |
OMRON R7D-BPA5L Servo AC 100VAC Supply 1A 100V Load 50 W Single phase input
Product information OMRON R7D-BPA5L :
• Standard and high inertia servo motor models
• Peak torque 300% of rated torque during 3 seconds or more depending on model
• High resolution serial encoder provided by 20 bits encoder
• IP67 protection in all models
• Ultra-light and compact size motor
• Low speed ripple and low torque ripple due to low torque cogging
• Various shaft, brake and seal options
Same series of R88 - :
R88D-GN04H-ML2 : G-Series servo drive, 1~ 200 VAC, MECHATROLINK II integrated, 400 W
R88M-G40030H-BS2 : G-Series/SmartStep 2 AC servo motor (cylinder type), 400 W, 200 VAC, 3000 rpm, 1.3 Nm, with brake
R88M-G40030H-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, incremental, Brake, with circular connector
R88M-G40030T-BS2: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake
R88M-G40030T-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake, with circular connector
R88M-GP40030T-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake, with circular connector
Details:
Similar Model Products:
Specifications | Model | |
---|---|---|
Single-phase 100 VAC | 50 W | R7D-BPA5L |
100 W | R7D-BP01L | |
200 W | R7D-BP02L | |
Single-phase/three-phase 200 VAC | 50 W | R7D-BP01H |
100 W | ||
400 W | R7D-BP04H | |
Single-phase 200 VAC | 200 W | R7D-BP02HH |
Three-phase 200 VAC | 200 W | R7D-BP02H |
Item | Specifications | ||
---|---|---|---|
Ambient operating temperature Ambient operating humidity |
0 to 55 °C, 90% max. (with no condensation) | ||
Ambient storage temperature Ambient storage humidity |
-20 to 65 °C, 90% max. (with no condensation) | ||
Storage and operating atmosphere | No corrosive gasses, no dust, no iron dust, no exposure to moisture or cutting oil |
||
Vibration resistance | 10 to 60 Hz; acceleration: 5.9 m/s2 (0.6 G) max. | ||
Impact resistance | Acceleration of 19.6 m/s2 max. 3 times each in X, Y, and Z directions. | ||
Insulation resistance | Between power supply/power line terminals and frame ground: 0.5 MΩ. min. (at 500 VDC) |
||
Dielectric strength | Between power supply/power line terminals and frame ground: 1,500 VAC for 1 min at 50/60 Hz Between each control signal and frame ground: 500 VAC for 1 min |
||
Altitude | 1,000 m above sea level max. (860 hp min.) | ||
Degree of protection | Built into panel (IP10). | ||
International standards |
EC Directives |
EMC Directive | EN 55011 class A group 1 EN 61000-6-2 |
Low Voltage Directive |
EN 50178 | ||
UL standards | UL 508C | ||
cUL standards | cUL C22.2 No.14 | ||
Korean Radio Regulations (KC) |
Certified |
Specifications | Model | |
---|---|---|
Power Model Supply Voltage | Applicable Servomotor Capacity | |
Single-phase 100 VAC |
50 W | R88D-KTA5L |
100 W | R88D-KT01L | |
200 W | R88D-KT02L | |
400 W | R88D-KT04L | |
Single-phase/three-phase 200 VAC |
100 W | R88D-KT01H |
200 W | R88D-KT02H | |
400 W | R88D-KT04H | |
750 W | R88D-KT08H | |
1 kW | R88D-KT10H | |
1.5 kW | R88D-KT15H | |
Three-phase 200 VAC |
2 kW | R88D-KT20H |
3 kW | R88D-KT30H | |
5 kW | R88D-KT50H | |
7.5 kW | R88D-KT75H | |
15 kW | R88D-KT150H | |
Three-phase 400 VAC |
600 W | R88D-KT06F |
1 kW | R88D-KT10F | |
1.5 kW | R88D-KT15F | |
2 kW | R88D-KT20F | |
3 kW | R88D-KT30F | |
5 kW | R88D-KT50F | |
7.5 kW | R88D-KT75F | |
15 kW | R88D-KT150F |
