Product Description
The printed circuit board known as DS215SLCCG2AZZ01B is one of several LAN Communications Cards available for General Electric’s Mark V turbine control system. There are three different versions of the SLCC board manufactured by GE: the SLCCG1A boards, SLCCG2A boards, and SLCCG4A boards. Please be sure to order the correct configuration for your system. This board includes circuitry for connecting the drive to DLAN networks only. If you need to connect to ARCNET, look at SLCCG1A versions of this board.
The DS215SLCCG2AZZ01B board is used within the Mark V system in conjunction with the SDCC drive control card. The main processor on the SLCC board is the LAN control processor located at U1. Software for the board is stored in replaceable EPROMS. These are located at U6 and U7. While the board is not software configurable, these EPROMS can be moved or replaced. Meanwhile, RAM for communications and dedicated RAM is located at U5, U8, and U9. Hardware configuration includes wire jumpers and several jumper switches.
The DS215SLCCG2AZZ01B board typically mounts onto the SDCC board using four standoffs connected into four factory drilled holes on the SLCC card.
Other board components include resistor network arrays, resistors, capacitors, vertical pin connectors, and a multi digit alphanumeric display
