AB 1326AB-B720E-M2K7L SERIES SERVO MOTOR 6.8 KILOWATTS OF MAXIMUM RATED OUTPUT

AB 1326AB-B720E-M2K7L SERIES SERVO MOTOR 6.8 KILOWATTS OF MAXIMUM RATED OUTPUT

Technical Specifications for 1326AB-B720E-M2K7L

Brand Allen-Bradley / Rockwell Automation
Series 1326 Motors
Part Number 1326AB-B720E-M2K7L
Description Torque Plus AC Servo Motor
Voltage 460 Volts AC
Power Rarting 6.2 Kilowatts
Rotor Speed 3000 TPM
Continuous Torque Rating 30.9 Newton-meter

Continous Stall Current Rating 17.5 Amps
Frame size 5.9 Inches
Magnet stack lenght 20 millimeters
Feedback Device Multi-turn High-Resolution Encoder
Holding Brake Option 24 Volt DC Spring-set
Approximate Weight 46.3 Kilograms
Connector Orientation Rear-end
Product Lifecycle Status* Discontinued/Obsolete

About 1326AB-B720E-M2K7L

The Allen-Bradley 1326AB-B720E-M2K7L Torque Plus AC Servo Motor is a high-performance AC motor designed for high-performance servo system applications. The 1326AB-B720E-M2K7L Servo Motor comes with a normally closed-type thermal switch (that offers thermal-overload indication), a TENV design, and a 100% continuous torque rating at zero RPM as standard motor features. It has a standard three-phase voltage rating of 460 Volts AC, and it has an acceptable operating range from 380 Volts AC to 460 Volts AC. The 1326AB-B720E-M2K7L Servo Motor has a maximum power rating of 6.8 Kilowatts and a base motor speed of 3000 RPM (maximum) at 460 Volts AC. The 1326AB-B720E-M2K7L Servo Motor has a system torque rating of 30.9 Newton-meter (N-m) and a continuous stall current rating of 17.5 Amps.

The 1326AB-B720E-M2K7L Servo Motor has a multi-turn high-resolution encoder that provides absolute position feedback within 4096 resolutions and it requires no battery This motor has a spring-set holding brake option (24 Volts DC type) with up to 400 pounds on an inch of holding torque. The 1326AB-B720E-M2K7L Servo Motor has a 5.91-inch frame diameter and a magnet stack length of 20 millimeters. It has an IP 67 standard environmental protection rating that can offer water-tight protection when the motor is temporarily submerged in water. This servo motor also comes with a built-in shaft oil seal that provides dust-tight protection. The 1326AB-B720E-M2K7L Servo Motor has an environmentally sealed connector cable (feedback/power) and a rear-exit type connector orientation. The 1326AB-B720E-M2K7L Servo Motor has an operating temperature range of 0 to 40 degrees Celsius and an approximate motor weight of 102 pounds. It has a maximum operational shock withstand of 10 g (for 6 milliseconds) and it is designed for 5 to 95% relative humidity.
