| Item |
Description |
| SYPT-LITE |
Programming tool for drive's with built in PLC capability and SM-Apps Lite Module |
| SYPTPRO |
Coprocessor module programming and CTNet system configuration tool, Software registration required |
| SM-APPLICATIONS |
Applications Solutions Module, Programmable with SyPT via CTNet or RS485, 2 digital inputs and 2 digital outputs for high speed I/O operations |
| SM-APPS-LITE |
Applications Lite Solutions Module, Programmable with SyPT or SyPT Lite |
| SM-APPS-LITE-PLUS |
Applications Lite Solutions Module with faster processor, Programmable with SyPT or SyPT Lite |
| SM-APPS-PLUS |
Applications Solutions Module with faster processor, Programmable with SyPT via CTNet or RS485, 2 digital inputs and 2 digital outputs for high speed I/O operations |
| SM-EZMOTION |
Motion Made Easy Solutions Module, Utilizing PowerTools programming software |
| SM-ETC |
15 Pin D Shell to 15 pin screw terminal break out board for servo and vector motor encoder feedback cable |
| DST-KEYPAD |
LED Keypad, Configured for Digitax ST |
| SM-HEATSINK-DBR1 |
DB Resistor, 75 Ohm, 50 Watt, Heatsink for Unidrive SP size 1 & Epsilon EP |
| SM-HEATSINK-DBR2 |
DB Resistor, 37.5 Ohm, 100 Watt, Heatsink for Unidrive SP size 2 |
| BRM-1 |
Brake Relay module, 24V, 1 contact, 6 amp, DIN rail mounting (EN, EP, Epsilon, MDS to CBMS, CBMF, XTBMS, XCMDBS) |
| 4200-6000 |
EMC (RFI) Filter, amps, 230V 1 input, Panel Mount |
| 4200-6001 |
EMC (RFI) Filter, amps, 230V 3 input, Panel Mount |
| 4200-6002 |
EMC (RFI) Filter, amps, 460V 3 input, Panel Mount |
| SM-ENCODER-OUT |
Incremental Encoder Output Solution Module to enable connection with external motion controllers |
| SM-ENCODER-PLUS |
Encoder Plus Solutions Module, provides an additional incremental encoder feedback port. |
| SM-UNI-ENCODER |
Universal Encoder Plus Solutions Module, provides an additional increamental or Absolute encoder feedback port and simulated encoder output. |
| SM-RESOLVER |
Resolver Solutions Module, providing a resolver feedback port, w/simulated encoder output |
| SM-I/O-120 |
I/O Solutions Module, 6 inputs (120Vac) or 3 inputs (240Vac) & 2 Relay Outputs (2A @ 240Vac or 4A@30Vdc) |
| SM-I/O-24V |
I/O Solutions Module, 24V Protected, 3 DI, 4 DI/DO, 2 Relay Outputs, 2 current AO |
| SM-I/O-32 |
I/O Solutions Module with (32) Assignable 24VDC Digital Inputs/Outputs (Requires application programming.) |
| SM-I/O-LITE |
I/O Lite Solutions Module - (1) +/- 10V Bi-polar or 4-20mA input, (3) digital inputs, (1)? 0-10V or 4-20mA output, (1) relay output, (1) Incremental Encoder Speed Reference input |
| SM-I/O-PLUS |
I/O Solutions Module, High Performance, (2) +/- 10V analog input, (1)? +/- 10V? output, (3) digital inputs, (3) programmable digital I/O,? (2) relay output, |
| SM-I/O-TIMER |
I/O Lite Solutions Module w/real time clock for scheduling events, (1) +/- 10V Bi-polar or 4-20mA input, (3) digital inputs, (1)? 0-10V or 4-20mA output, (1) relay output, (1) Incl Enc Spd Ref input |
