Horner Automation HE693RTD601 Automation Product RTD input module PLC I/O Horner Electric

GE HE693RTD601 Automation Product RTD input module PLC I/O Horner Electric

Product description

The Horner HE693RTD601 is an RTD input module that has six channels. These inputs permit the direct connection between the PLC and RTD temperature sensors without the need for external signal processing such as transmitters and transducers. The HE693RTD601 analog and digital processing are done inside the module. This module offers a temperature resolution of 0.125 degrees Celsius, 0.1 degrees Celsius, or 0.1 degrees Fahrenheit. The HE693RTD601 can detect the issue due to the open circuit.

Technical Specifications

The Horner HE693RTD601 is an RTD input module that has six channels. These inputs permit the direct connection between the PLC and RTD temperature sensors without the need for external signal processing such as transmitters and transducers. The HE693RTD601 analog and digital processing are done inside the module. This module offers a temperature resolution of 0.125 degrees Celsius, 0.1 degrees Celsius, or 0.1 degrees Fahrenheit. The HE693RTD601 can detect the issue due to the open circuit. The input module can employ a wire with a cross-section area of 0.205 square millimeters (24 AWG). This module supports the integrating A/D conversion type with a scan rate of fifty channels per second and a resolution of 16 bits.

The module inputs support linear resistance, TD5R and PT-90, 100E, 100C, 100Z, and 1000 with an input temperature range from -200 degrees to 850 degrees Celsius (-328 degrees to 1562 degrees Fahrenheit). This module draws a current of 75 milliamperes at a voltage of +5 volts DC. The HE693RTD601 has an input impedance of 1 gigaohm. This module employs the Zener diode clamp approach as fault protection. The input module offers an accuracy of ± 0.5 degrees Celsius (±32.9 degrees Fahrenheit). This module can be employed with Series 90-30 PLCs. The input module supports a relative humidity range from 5 percent to 95 percent without condensing. The HE693RTD601 weighs approximately 320 grams (0.7 pounds) while shipping and operates at 0 degrees to 60 degrees Celsius (32 degrees to 140 degrees Fahrenheit) for industrial applications.
