| Place of Origin: | Singapore |
| Brand Name: | ROSEMOUNT |
| Certification: | Does not supply |
| Model Number: | 5408A1SHA1E51R3ABCAB3M5DA1 |
| Minimum Order Quantity: | 1 ea |
|---|---|
| Price: | Negotiate |
| Packaging Details: | In Box |
| Delivery Time: | 10-12weeks |
| Payment Terms: | T/T,PAYONEER |
| Supply Ability: | 10EA |
| BRAND: | EMERSON ROSEMOUNT | MODEL: | 5408A1SHA1E51R3ABCAB3M5DA1 |
|---|---|---|---|
| CATEGORY: | Level Transmitter | SUPPLY: | 4–20 MA |
| Measurement Type: | Liquid Level Measurement | Delivery Time: | 6 Weeks |
| High Light: | 5408A1SHA1E51R3ABCAB3M5DA1 Pressure Temperature Transmitter,20mA Pressure Temperature Transmitter,Level Transmitter Rosemount 5408 |
||
5408A1SHA1E51R3ABCAB3M5DA1 Level Transmitter Rosemount 5408 HART Revision 7
Product Information Of : 5408A1SHA1E51R3ABCAB3M5DA1
| Brand | EMERSON ROSEMOUNT |
| Model | 5408A1SHA1E51R3ABCAB3M5DA1 |
| SUPPLY |
4–20 mA |
| SIZE | Does not supply |
| Weight | Does not supply |
The Rosemount 5408 is a two-wire non-contacting radar transmitter for level measurements over a broad range of liquids and slurries. It uses a unique energy efficient radar technology based on the FMCW principle to ensure reliable performance even in challenging conditions.
(1)G½ thread form is not available with hazardous locations approvals.
(2)Only available with 4-20 mA HART protocol.
(3)Type A flat face for EN 1092-1 flanges.
(4)Type B1 raised face for EN 1092-1 flanges.
(5)Pressure limit is derated for process temperatures above 100 °F (38 °C), see Figure 6 for details.
(6)Option code PC1 is for cone antennas only, and requires matching flange and antenna sizes. Note that all parabolic antennas come with an integrated air purge connection.
(7)A minimum gasket thickness of 0.125 in. (3.2 mm) is required for flanges with protective plate design.
(8)Only available with parabolic antenna and 4-in. (DN100) cone antenna.
More options :
3051CG1A02A1AB1H2L4M5
3051CG5A02A1AB3H2L4M5
3051CG1A02A1AB1H2L4M5K5
3051CG2A02A1AB1H2L4M5K5
3051CG5A02A1AB1H2L4M5
3051CG4A02A1AB3H2L4M5
3051CG2A02A1AB1H2L4M5
3051CG3A02A1AB1H2L4M5
3051CG4A02A1AB1H2L4M5
3051CG1A02A1AB3H2L4M5
3051CG2A02A1AB3H2L4M5
3051CG3A02A1AB3H2L4M5
MR-J2S-60B-S041U638
MR-J2S-60B-S134
MR-J2S-60B-S030
MR-J2S-40B-PY096T018
MR-J2S-40B-PY135
MR-J2S-40B1-EH018
MR-J2S-40B1-QA112
MR-J2S-40CP1
MR-J2S-20CP1
MR-J2S-10CP1
MR-J2S-40B-QT0009U625
MR-J2S-40A-S004
MR-J2S-10A1-S017
MR-J2S-20A-S011
MR-J2S-40A-S011
MR-J2S-70A-S011
MR-J2S-100A-S011
MR-J2S-200A-S011
MR-J2S-10A-S075
MR-J2S-70CP-S186
Rosemount 5408 Level Transmitter Information:
| Model | Product Description | |
| 5408 | Radar Level Transmitter | ★ |
| Profile | ||
| A | Standard Monitoring & Control Applications | ★ |
| Measurement type | ||
| 1 | Liquid Level Measurement | ★ |
| 3 | Solids Level Measurement | ★ |
| 4 | Liquid & Solids Level Measurement | ★ |
| Performance class | ||
| S | Standard | ★ |
| Signal output | ||
| H | 4–20 mA with digital signal based on HART® Revision 6 protocol (HART Revision 7 available as option) | ★ |
| F | FOUNDATION™ Fieldbus | ★ |
| Housing material | ||
| A | Aluminum | ★ |
| S | Stainless Steel (SST) | ★ |
| Conduit/cable threads | ||
| 1 | ½-14 NPT | ★ |
| 2 | M20 x 1.5 | ★ |
| 3(1) | G½ | |
| Hazardous locations certifications | ||
| NA | None | ★ |
| E1 | ATEX Flameproof | ★ |
| I1 | ATEX Intrinsic Safety | ★ | |
| N1 | ATEX Type n | ★ | |
| IA | ATEX FISCO Intrinsic Safety | ★ | |
| E5 | USA Explosion-proof, Dust Ignition-proof | ★ | |
| I5 | USA Intrinsically Safe; Nonincendive | ★ | |
| IE | USA FISCO Intrinsic Safety | ★ | |
| E6 | Canadian Explosion-proof, Dust Ignition-proof | ★ | |
| I6 | Canadian Intrinsically Safe; Nonincendive | ★ | |
| IF | Canadian FISCO Intrinsic Safety | ★ | |
| E7 | IECEx Flameproof, Dust Ignition-proof | ★ | |
| I7 | IECEx Intrinsic Safety | ★ | |
| N7 | IECEx Type n | ★ | |
| IG | IECEx FISCO Intrinsic Safety | ★ | |
| E2(2) | INMETRO Flameproof | ★ | |
| I2(2) | INMETRO Intrinsic Safety | ★ | |
| N2(2) | INMETRO Type n | ★ | |
| E3(2) | China Flameproof | ★ | |
| I3(2) | China Intrinsic Safety | ★ | |
| N3(2) | China Type n | ★ | |
| E4(2) | Japan Flameproof | ★ | |
| EP(2) | Republic of Korea Flameproof | ★ | |
| IP(2) | Republic of Korea Intrinsic Safety | ★ | |
| EM(2) | Technical Regulations Customs Union (EAC) Flameproof | ★ | |
| IM(2) | Technical Regulations Customs Union (EAC) Intrinsic Safety | ★ | |
| NM(2) | Technical Regulations Customs Union (EAC) Type n | ★ | |
| Materials of construction | Available antenna types | ||
| 1 | 316/316L/EN 1.4404 | Cone, Parabolic | ★ |
| 7 | All PTFE Wetted Parts | Process Seal | ★ |
| 2 | Alloy C-276 (UNS N10276) with Protective Plate | Cone | |
| 3 | Alloy 400 (UNS N04400) with Protective Plate | Cone | |
| H | Alloy C-276 (UNS N10276) Process Connection, Flange, and Antenna | Cone | |
| M | Alloy 400 (UNS N04400) Process Connection, Flange, and Antenna | Cone | |
| Process connection type (see Table 3, Table 4, Table 5, and Table 6) | Available antenna types | ||
| F(3) | Flat Face Flange | Cone, Parabolic | ★ |
| R(4) | Raised Face Flange | All | ★ |
| N | NPT Thread | Cone | ★ |
| G | BSPP (G) Thread | Cone, Parabolic | ★ | |
| B | Bracket Mounting | Cone | ★ | |
| C | Tri-Clamp® | Process Seal | ★ | |
| W | Welded Connection | Parabolic | ★ | |
| T | Ring Type Joint (RTJ) Flange | Cone | ||
| Process connection size (see Table 3, Table 4, Table 5, and Table 6) | Available antenna types | |||
| A | 1½-in. | Cone | ★ | |
| 2 | 2-in./DN50/50A | Cone, Process Seal | ★ | |
| 3 | 3-in./DN80/80A | Cone, Process Seal | ★ | |
| B | 3½-in. | Parabolic | ★ | |
| 4 | 4-in./DN100/100A | Cone, Process Seal | ★ | |
| 6 | 6-in./DN150/150A | Cone | ★ | |
| 8 | 8-in./DN200/200A | Cone, Parabolic | ★ | |
| T | 10-in./DN250/250A | Parabolic | ★ | |
| Z | None (use when ordering bracket mounting) | Cone | ★ | |
| Process connection rating (see Table 3, Table 4, Table 5, and Table 6) | ||||
| ZZ | For use with non-flange process connection type | ★ | ||
| ASME flanges | ||||
| AA | ASME B16.5 Class 150 | ★ | ||
| AB | ASME B16.5 Class 300 | ★ | ||
| AC | ASME B16.5 Class 600 | ★ | ||
| EN flanges | Note | |||
| DK | EN1092-1 PN6 | ★ | ||
| DA | EN1092-1 PN16 | PN10 and PN16 dimensions are identical for DN50 to DN150 | ★ | |
| DB | EN1092-1 PN40 | PN25 and PN40 dimensions are identical for DN50 to DN150 | ★ | |
| DC | EN1092-1 PN63 | ★ | ||
| DD | EN1092-1 PN100 | ★ | ||
| JIS flanges | ||||
| JK | JIS 5K | ★ | ||
| JA | JIS 10K | ★ | ||
| JB | JIS 20K | ★ | ||
| Antenna type(5) | Operating pressure | Operating temperature | ||
| CAA | Cone Antenna (PTFE seal) | -15 to 363 psig (-1 to 25 bar) | -76 to 392 °F (-60 to 200 °C) | ★ |
| CAB | Cone Antenna (PTFE seal) | -15 to 725 psig (-1 to 50 bar)(6) | -40 to 302 °F (-40 to 150 °C) | ★ |
| CAC | Cone Antenna (PTFE seal) | -15 to 1450 psig (-1 to 100 bar) | -40 to 212 °F (-40 to 100 °C) | ★ |
| CAD | Cone Antenna (PTFE seal) | -15 to 44 psig (-1 to 3 bar) | -76 to 482 °F (-60 to 250 °C) |
★ |
| CBF | Cone Antenna (PEEK seal, FVMQ) | -15 to 754 psig (-1 to 52 bar) | -76 to 338 °F (-60 to 170 °C) | ★ |
| CBK | Cone Antenna (PEEK seal, Kalrez® 6375) | -15 to 754 psig (-1 to 52 bar) | 5 to 482 °F (-15 to 250 °C) | ★ |
| CBM | Cone Antenna (PEEK seal, FKM) | -15 to 754 psig (-1 to 52 bar) | -13 to 428 °F (-25 to 220 °C) | ★ |
| CBV | Cone Antenna (PEEK seal, Viton®) | -15 to 754 psig (-1 to 52 bar) | -22 to 392 °F (-30 to 200 °C) | ★ |
| SAA | Process Seal Antenna | -7 to 363 psig (-0.5 to 25 bar)(7) | -76 to 392 °F (-60 to 200 °C)(7) | ★ |
| PAS | Parabolic Antenna, Swivel Mount | -7 to 43 psig (-0.5 to 3 bar) | -67 to 392 °F (-55 to 200 °C) | ★ |
| Antenna size | Available antenna types | |||
| 2 | 2-in. (DN50) | Cone, Process Seal | ★ | |
| 3 | 3-in. (DN80) | Cone, Process Seal | ★ | |
| 4 | 4-in. (DN100) | Cone, Process Seal | ★ | |
| 8 | 8-in. (DN200) | Parabolic | ★ | |
| Options (include with selected model number) | ||||
| Antenna extensions (see Figure 22) | Total length | |||
| S1 | Extended Cone Antenna | 23.6-in. (600 mm) | ★ | |
| S2 | Extended Cone Antenna, Segmented | 47.2-in. (1200 mm) | ★ | |
| Purging connection (see Figure 12)(8)(9) | ||||
| PC1 | Purging Connector (Purge Ring) | ★ | ||
| Display | ||||
| M5 | LCD Display | ★ | ||
| Diagnostic functionality (see Smart Diagnostics Suite) | ||||
| DA1 | HART Smart Diagnostics Suite | ★ | ||
| D01 | FOUNDATION Fieldbus Smart Diagnostics Suite | ★ | ||
| HART revision configuration | ||||
| HR7 | 4-20 mA with digital signal based on HART Revision 7 protocol | ★ | ||
| Open air applications configuration(10) | ||||
| OA | Open Air Applications Configuration; LPR (Level Probing Radar) | ★ | ||
| Factory configuration | ||||
| C1 | Factory Configuration per Configuration Data Sheet | ★ | ||
| Alarm limits | ||||
| C4 | NAMUR Alarm and Saturation Levels, High Alarm | ★ | ||
| C5 | NAMUR Alarm and Saturation Levels, Low Alarm | ★ | ||
| C8(11) | Standard Rosemount Alarm and Saturation Levels, Low Alarm | ★ | ||
| Welding standard for flanges(12)(13) | ||||
| AW | According to ASME IX | ★ | ||
| EW | According to EN-ISO | ★ | ||
| Country certification(14) | ||
| J1 | Canadian Registration (CRN) | ★ |
| Special quality assurance | ||
| Q4 | Calibration Data Certificate | ★ |
| QG | Calibration Certificate and GOST Verification Certificate (only for end-destination country Russia) | |
| Hydrostatic testing(15) | ||
| Q5 | Hydrostatic Testing, including certificate | ★ |
| Material traceability certification(16) | ||
| Q8 | Material Traceability Certification per EN 10204 3.1 (2.1 for non-metallic) | ★ |
| Hygienic certification(17) | ||
| QA | Certificate of compliance to 3-A® | ★ |
| Food and Drug Administration (FDA) statement(17)(18) | ||
| QH | Certificate of Compliance to FDA | ★ |
| Materials certification(19) | ||
| Q15 | NACE® Material Recommendation per NACE MR0175/ISO 15156 | ★ |
| Q25 | NACE Material Recommendation per NACE MR0103/ISO 17945 | ★ |
| Q35 | NACE Material Recommendation per NACE MR0175/ISO 15156 and NACE MR0103/ISO 17945 | ★ |
| Welding procedure qualification record documentation(12) | ||
| Q66 | Welding Procedure Qualification Record (WPQR) | ★ |
| Q67 | Welder Performance Qualification (WPQ) | ★ |
| Q68 | Welding Procedure Specification (WPS) | ★ |
| Q79 | WPQR/WPQ/WPS | ★ |
| Dye penetration test certificate(12) | ||
| Q73 | Certificate of Liquid Penetrant Inspection | ★ |
| Positive material identification certificate | ||
| Q76 | Positive Material Identification Certificate of Conformance | ★ |
| Overfill prevention(2) | ||
| U1 | Overfill Prevention According to WHG/TUV | ★ |
| Shipboard approvals(2)(20) | ||
| SBS | American Bureau of Shipping Type Approval | ★ |
| SDN | Det Norske Veritas Germanischer Lloyd (DNV GL) Type Approval | ★ |
| SLL | Lloyd's Register Type Approval | ★ |
| SBV | Bureau Veritas Type Approval | ★ |
| Extended product warranty(21) | ||
| WR3 | 3-year Limited Warranty | ★ |
| WR5 | 5-year Limited Warranty | ★ |
| Conduit electrical connector (shipped uninstalled)(22) | ||
| EC | M 12, 4-pin, Male connector (eurofast®) | ★ |
| MC | A size Mini, 4-pin, Male connector (minifast®) | ★ |
| Specials (see Engineered solutions) | ||
| PXXXX | Custom Engineered Solutions beyond standard model codes. Consult factory for details. | |
| Typical model number: 5408 A 1 S H A 1 E5 1 R 3 AB CAB 3 M5 DA1 | ||
