5408F1SHA1E51R3ABCAB3M5DA1EF2QT Radar Level Transmitter 5408 SIS Level Transmitter
Product Information Of : 5408F1SHA1E51R3ABCAB3M5DA1EF2QT
(1)A minimum gasket thickness of 0.125 in. (3.2 mm) is required for flanges with protective plate design.
(2)The standard alarm setting is high.
(3)Only applies to flanged process connections with welded construction or protective plate design; only applicable to cone antennas
(4)Flanged process connections with protective plate design are only available with ASME IX (option code AW).
(5)Not available with EN1092-1 or JIS B2220 flanges, neither for ASME B16.5 flanges in materials of construction code M.
(6)Hydrostatic testing is only available for cone antennas and process seal antennas with flanged process connections.
| Brand | EMERSON ROSEMOUNT |
| Model | 5408F1SHA1E51R3ABCAB3M5DA1EF2QT |
| SUPPLY |
4–20 mA with digital signal based on HART® Revision 6 protocol |
| SIZE | No |
| Weight | Does not supply |
More options :
SGDA-A3VP
SGDA-A3VS
SGDA-A5AP
SGDA-A5AS
SGDA-A5ASY109
SGDA-A5BP
SGDA-A5BS
SGDA-A5VP
SGDA-A5VPY197
SGDA-A5VS
SGDB-02ADB
SGDB-02ADG
SGDB-03ADB
SGDB-03ADG
SGDB-03ADM
SGDB-05AD
SGDB-05ADG
SGDB-07ADM
SGDB-07ADM +SGMG-06A2BBB
SGDB-10AD
Rosemount 5408:SIS Level Transmitter Information:
| Model | Product Description | |
| 5408 | Radar Level Transmitter | ★ |
| Profile(1) | ||
| F | Functional Safety / SIS Applications | ★ |
| Measurement type | ||
| 1 | Liquid Level Measurement | ★ |
| 4(2) | Liquid & Solids Level Measurement | ★ |
| Performance class | ||
| S | Standard | ★ |
| Signal output | ||
| H | 4–20 mA with digital signal based on HART® Revision 6 protocol (HART Revision 7 available as option) | ★ |
| Housing material | ||
| A | Aluminum | ★ |
| S | Stainless Steel (SST) | ★ |
| Conduit/cable threads | ||
| 1 | ½-14 NPT | ★ |
| 2 | M20 x 1.5 | ★ |
| 3(3) | G½ | |
| Hazardous locations certifications | ||
| NA | None | ★ |
| E1 | ATEX Flameproof | ★ |
| I1 | ATEX Intrinsic Safety | ★ |
| N1 | ATEX Type n | ★ |
| E5 | USA Explosion-proof, Dust Ignition-proof | ★ |
| I5 | USA Intrinsically Safe; Nonincendive | ★ |
| E6 | Canadian Explosion-proof, Dust Ignition-proof | ★ | |
| I6 | Canadian Intrinsically Safe; Nonincendive | ★ | |
| E7 | IECEx Flameproof, Dust Ignition-proof | ★ | |
| I7 | IECEx Intrinsic Safety | ★ | |
| N7 | IECEx Type n | ★ | |
| E2 | INMETRO Flameproof | ★ | |
| I2 | INMETRO Intrinsic Safety | ★ | |
| N2 | INMETRO Type n | ★ | |
| E3 | China Flameproof | ★ | |
| I3 | China Intrinsic Safety | ★ | |
| N3 | China Type n | ★ | |
| E4 | Japan Flameproof | ★ | |
| EP | Republic of Korea Flameproof | ★ | |
| IP | Republic of Korea Intrinsic Safety | ★ | |
| EM | Technical Regulations Customs Union (EAC) Flameproof | ★ | |
| IM | Technical Regulations Customs Union (EAC) Intrinsic Safety | ★ | |
| NM | Technical Regulations Customs Union (EAC) Type n | ★ | |
| Materials of construction | Available antenna types | ||
| 1 | 316/316L/EN 1.4404 | Cone, Parabolic | ★ |
| 7 | All PTFE Wetted Parts | Process Seal | ★ |
| 2 | Alloy C-276 (UNS N10276) with Protective Plate | Cone | |
| 3 | Alloy 400 (UNS N04400) with Protective Plate | Cone | |
| H | Alloy C-276 (UNS N10276) Process Connection, Flange, and Antenna | Cone | |
| M | Alloy 400 (UNS N04400) Process Connection, Flange, and Antenna | Cone | |
| Process connection type (see Table 3, Table 4, Table 5, and Table 6) | Available antenna types | ||
| F(4) | Flat Face Flange | Cone, Parabolic | ★ |
| R(5) | Raised Face Flange | All | ★ |
| N | NPT Thread | Cone | ★ |
| G | BSPP (G) Thread | Cone, Parabolic | ★ |
| B | Bracket Mounting | Cone | ★ |
| C | Tri-Clamp | Process Seal | ★ |
| W | Welded Connection | Parabolic | ★ |
| T | Ring Type Joint (RTJ) Flange | Cone | |
| Process connection size (see Table 3, Table 4, Table 5, and Table 6) | Available antenna types | ||
| A | 1½-in. | Cone | ★ |
| 2 | 2-in./DN50/50A | Cone, Process Seal | ★ |
| 3 | 3-in./DN80/80A | Cone, Process Seal | ★ | |
| B | 3½-in. | Parabolic | ★ | |
| 4 | 4-in./DN100/100A | Cone, Process Seal | ★ | |
| 6 | 6-in./DN150/150A | Cone | ★ | |
| 8 | 8-in./DN200/200A | Cone, Parabolic | ★ | |
| T | 10-in./DN250/250A | Parabolic | ★ | |
| Z | None (use when ordering bracket mounting) | Cone | ★ | |
| Process connection rating (see Table 3, Table 4, Table 5, and Table 6) | ||||
| ZZ | For use with non-flange process connection type | ★ | ||
| ASME flanges | ||||
| AA | ASME B16.5 Class 150 | ★ | ||
| AB | ASME B16.5 Class 300 | ★ | ||
| AC | ASME B16.5 Class 600 | ★ | ||
| EN flanges | Note | |||
| DK | EN1092-1 PN6 | ★ | ||
| DA | EN1092-1 PN16 | PN10 and PN16 dimensions are identical for DN50 to DN150 | ★ | |
| DB | EN1092-1 PN40 | PN25 and PN40 dimensions are identical for DN50 to DN150 | ★ | |
| DC | EN1092-1 PN63 | ★ | ||
| DD | EN1092-1 PN100 | ★ | ||
| JIS flanges | ||||
| JK | JIS 5K | ★ | ||
| JA | JIS 10K | ★ | ||
| JB | JIS 20K | ★ | ||
| Antenna type(6) | Operating pressure | Operating temperature | ||
| CAA | Cone Antenna (PTFE seal) | -15 to 363 psig (-1 to 25 bar) | -76 to 392 °F (-60 to 200 °C) | ★ |
| CAB | Cone Antenna (PTFE seal) | -15 to 725 psig (-1 to 50 bar)(7) | -40 to 302 °F (-40 to 150 °C) | ★ |
| CAC | Cone Antenna (PTFE seal) | -15 to 1450 psig (-1 to 100 bar) | -40 to 212 °F (-40 to 100 °C) | ★ |
| CAD | Cone Antenna (PTFE seal) | -15 to 44 psig (-1 to 3 bar) | -76 to 482 °F (-60 to 250 °C) | ★ |
| CBF | Cone Antenna (PEEK seal, FVMQ) | -15 to 754 psig (-1 to 52 bar) | -76 to 338 °F (-60 to 170 °C) | ★ |
| CBK | Cone Antenna (PEEK seal, Kalrez® 6375) | -15 to 754 psig (-1 to 52 bar) | 5 to 482 °F (-15 to 250 °C) | ★ |
| CBM | Cone Antenna (PEEK seal, FKM) | -15 to 754 psig (-1 to 52 bar) | -13 to 428 °F (-25 to 220 °C) | ★ |
| CBV | Cone Antenna (PEEK seal, Viton®) | -15 to 754 psig (-1 to 52 bar) | -22 to 392 °F (-30 to 200 °C) | ★ |
| SAA | Process Seal Antenna | -7 to 363 psig (-0.5 to 25 bar)(8) | -76 to 392 °F (-60 to 200 °C)(8) | ★ |
| PAS | Parabolic Antenna, Swivel Mount | -7 to 43 psig (-0.5 to 3 bar) | -67 to 392 °F (-55 to 200 °C) | ★ |
| Antenna size | Available antenna types | |||
| 2 | 2-in. (DN50) | Cone, Process Seal | ★ | |
| 3 | 3-in. (DN80) | Cone, Process Seal | ★ |
| 4 | 4-in. (DN100) | Cone, Process Seal | ★ |
| 8 | 8-in. (DN200) | Parabolic | ★ |
| Options (include with selected model number) | |||
| Antenna extensions (see Figure 22) | Total length | ||
| S1 | Extended Cone Antenna | 23.6-in. (600 mm) | ★ |
| S2 | Extended Cone Antenna, Segmented | 47.2-in. (1200 mm) | ★ |
| Purging connection (see Figure 12)(9)(10) | |||
| PC1 | Purging Connector (Purge Ring) | ★ | |
| Display | |||
| M5 | LCD Display | ★ | |
| Functional safety options | |||
| EF2 | Extended SIS Package | ★ | |
| Diagnostic functionality (see Smart Diagnostics Suite) | |||
| DA1 | HART Smart Diagnostics Suite | ★ | |
| HART revision configuration | |||
| HR7 | 4-20 mA with digital signal based on HART Revision 7 protocol | ★ | |
| Factory configuration | |||
| C1 | Factory Configuration per Configuration Data Sheet | ★ | |
| Alarm limits | |||
| C4 | NAMUR Alarm and Saturation Levels, High Alarm | ★ | |
| C5 | NAMUR Alarm and Saturation Levels, Low Alarm | ★ | |
| C8(11) | Standard Rosemount Alarm and Saturation Levels, Low Alarm | ★ | |
| Welding standard for flanges(12)(13) | |||
| AW | According to ASME IX | ★ | |
| EW | According to EN-ISO | ★ | |
| Country certification(14) | |||
| J1 | Canadian Registration (CRN) | ★ | |
| Special quality assurance | |||
| Q4 | Calibration Data Certificate | ★ | |
| QG | Calibration Certificate and GOST Verification Certificate (only for end-destination country Russia) | ||
| Hydrostatic testing(15) | |||
| Q5 | Hydrostatic Testing, including certificate | ★ | |
| Material traceability certification(16) | |||
| Q8 | Material Traceability Certification per EN 10204 3.1 (2.1 for non-metallic) | ★ | |
| Hygienic certification(17) | ||
| QA | Certificate of compliance to 3-A® | ★ |
| Food and Drug Administration (FDA) statement(17)(18) | ||
| QH | Certificate of Compliance to FDA | ★ |
| Quality certification for safety | ||
| QS | Certificate of FMEDA Data | ★ |
| QT | Safety-certified to IEC 61508 with certificate of FMEDA data | ★ |
| Materials certification(19) | ||
| Q15 | NACE® Material Recommendation per NACE MR0175/ISO 15156 | ★ |
| Q25 | NACE Material Recommendation per NACE MR0103/ISO 17945 | ★ |
| Q35 | NACE Material Recommendation per NACE MR0175/ISO 15156 and NACE MR0103/ISO 17945 | ★ |
| Welding procedure qualification record documentation(12) | ||
| Q66 | Welding Procedure Qualification Record (WPQR) | ★ |
| Q67 | Welder Performance Qualification (WPQ) | ★ |
| Q68 | Welding Procedure Specification (WPS) | ★ |
| Q79 | WPQR/WPQ/WPS | ★ |
| Dye penetration test certificate(12) | ||
| Q73 | Certificate of Liquid Penetrant Inspection | ★ |
| Positive material identification certificate | ||
| Q76 | Positive Material Identification Certificate of Conformance | ★ |
| Overfill prevention | ||
| U1 | Overfill Prevention According to WHG/TUV | ★ |
| Shipboard approvals(20) | ||
| SBS | American Bureau of Shipping Type Approval | ★ |
| SDN | Det Norske Veritas Germanischer Lloyd (DNV GL) Type Approval | ★ |
| SLL | Lloyd's Register Type Approval | ★ |
| SBV | Bureau Veritas Type Approval | ★ |
| Extended product warranty(21) | ||
| WR3 | 3-year Limited Warranty | ★ |
| WR5 | 5-year Limited Warranty | ★ |
| Paint option for aluminum housing | ||
| PY1 | Housing and Covers in Yellow per RAL 1003 | ★ |
| PY2 | Covers in Yellow per RAL 1003 | ★ |
| PR1 | Housing and Covers in Red per RAL 3002 | ★ |
| PR2 | Covers in Red per RAL 3002 | ★ |
| PO1 | Housing and Covers in Orange per Munsell 2.5 YR 6/14 | ★ |
| PO2 | Covers in Orange per Munsell 2.5 YR 6/14 | ★ |
| Conduit electrical connector (shipped uninstalled)(22) | ||
| EC | M 12, 4-pin, Male connector (eurofast) | ★ |
| MC | A size Mini, 4-pin, Male connector (minifast) | ★ |
| Specials (see Engineered solutions) | ||
| PXXXX | Custom Engineered Solutions beyond standard model codes. Consult factory for details. | |
| Typical model number: 5408 F 1 S H A 1 E5 1 R 3 AB CAB 3 M5 DA1 EF2 QT | ||
