Name: NS12-TS00B-V2 Omron HMI Touch Screen NS8 Series 640 x 480pixels
Brand: Wisdomlong Technology CO.，LTD
SKU: NS12-TS00B-V2
Price: 1.00 USD
Availability: InStock

Home Products HMI Touch Screen

NS12-TS00B-V2 Omron HMI Touch Screen NS8 Series 640 x 480pixels

Product Details:

Place of Origin:	Japan
Brand Name:	Omron
Certification:	CE
Model Number:	NS12-TS00B-V2

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiated
Packaging Details:	New Original
Delivery Time:	3-5days
Payment Terms:	L/C, T/T
Supply Ability:	1000

Contact Now

Detailed Product Description

Brand:	Omron	Product Type:	NS12-TS00B-V2
Part Number:	NS12-TS00B-V2	Place Of Origin:	Japan
Onboard Memory:	40 MB	Supply Voltage:	24 V Dc

NS12-TS00B-V2 Omron HMI Touch Screen NS8 Series 640 x 480pixels

Product Details of NS12-TS00B-V2 Omron

Omron Touch-Screen HMI Display

The Omron NS8 8.4inch black touch-screen HMI display that provides a graphical touch screen interface for systems and machines. This can be controlled by Omron PLCs via an RS-232C connection at up to 115Kbps that gives the high-speed response to system/machine events and user input. This display has 2 X RS232 ports. It is available in black frame colour.

Features and Benefits

Programming via the USB port
Bright, high-definition TFT model
NS8 - 256 colours (32768 for . BMP/. JPG)
NS8 models feature a USB programming port (USB type B connector)
Standard objects supported includes alphanumeric data entry, analogue/level meters, bitmaps, trend graphs, animation, data log graphs (up to 160000 points), alarm event/history (5000 entries), and video display (video input supported by NS8 only, option card required)
Multi-language support (16 languages)
Compact flash slot used for software updates, data/alarm logging and recipe storage
Data can be stored in . CSV format
Backlight brightness adjustment 3 level
Resolution is 640x480pixels

Specifications

Attribute	Value
Manufacturer Series	NS8
Display Type	LCD
Display Size	8.4 in
Display Resolution	640 x 480pixels
Display Colour	Colour
Port Type	DB25, USB
Onboard Memory	40 MB
Backlighting	Yes
Supply Voltage	24 V dc
IP Rating	IP65
Minimum Operating Temperature	0°C
Maximum Operating Temperature	+50°C
Width	241mm
Length	315mm
Dimensions	315 x 241 x 48.5 mm
Depth	48.5mm
