Name: K3G250-RR17-H9 400VAC 1.15A Redundant Power Supply Module Germany Ebmpapst
Brand: Wisdomlong Technology CO.，LTD
SKU: K3G250-RR17-H9
Price: 1.00 USD
Availability: InStock

Home Products Industrial Centrifugal Fan

K3G250-RR17-H9 400VAC 1.15A Redundant Power Supply Module Germany Ebmpapst

Product Details:

Place of Origin:	Germany
Brand Name:	EBM
Model Number:	K3G250-RR17-H9

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negitiation
Packaging Details:	in box
Delivery Time:	3-5days
Payment Terms:	T/T, Western Union
Supply Ability:	100

Contact Now

Detailed Product Description

Product Name:	Industrial Centrifugal Fan K3G250-RR17-H9	Product:	Industrial Centrifugal Fan
Model:	K3G250-RR17-H9	Brand:	Ebmpapst
VAC:	230VAC	Packaging Quantity 1:	1
Commodity Code:	85371091	Country Of Origin:	Germany

K3G250-RR17-H9 400VAC 1.15A Redundant Power Supply Module Germany Ebmpapst

Quick Details

Type K3G250-RR17-J3
Motor M3G084-DF
Phase 3~
Nominal voltage 400VAC
Nominal voltage range VAC 380 .. 480
Frequency Hz 50/60
Method of obtaining data ml
Status prelim.
Speed (rpm) min-1 4250
Power consumption W 730
Current draw 1.15A
Min. ambient temperature °C -25
Max. ambient temperature °C 60

Technical description
Weight 0.001 kg
Size 250 mm
Motor size 84
Rotor surface Painted black
Electronics housing material Die-cast aluminum
Impeller material PA plastic
Support plate material Sheet steel, galvanized
Support bracket material Die-cast aluminum
Inlet nozzle material Sheet steel, galvanized
Guard grille material Steel, coated with pebble gray plastic (RAL 7032)
Number of blades 6
Direction of rotation Clockwise, viewed toward rotor
Degree of protection IP55
Insulation class "F"
Moisture (F) / Environmental (H)
protection class
H1
Max. permitted ambient temp.
for motor (transport/storage)
+80 °C
Min. permitted ambient temp. for
motor (transport/storage)
-40 °C
Installation position Shaft horizontal or rotor on bottom; rotor on top on request
Condensation drainage holes On rotor side
Mode S1
Motor bearing Ball bearing
Electrical hookup Connector with cable
Motor protection Thermal overload protector (TOP) internally connected
With cable Variable
Protection class I (with customer connection of protective earth)
Conformity with standards EN 61800-5-1; CE

OTHER SUPERIOR PRODUCTS

Yasakawa Motor, Driver SG-	Mitsubishi Motor HC-,HA-
Westinghouse Modules 1C-,5X-	Emerson VE-,KJ-
Honeywell TC-,TK-	GE Modules IC -
ABB Module	AB Module 1756-,1759- Tourch Screen 2711-
Mitsubishi Drive MR- , Motor HA -,HC	Emerson MoudlesVE- ,KJ -
Fanuc motor A0-, Drive	Yokogawa transmitter EJA-
Rosemount Transmitter 3051-	Schneider Module 140-
Panasonic Motor , Drive MH-	Siemens Module 6ES-, Touch Screen 6AV-

A2D300-AP02-01;S2D300-BP02-30;W2D300-CP02-30;S2D300-AP02-30;A2D300-AP02-02;S2D300-BP02-31
W2D300-CP02-31;S2D300-AP02-31;A2E300-AP02-01;S2E300-BP02-30;W2E300-CP02-30;S2E300-AP02-30
A2E300-AP02-02;S2E300-BP02-31;W2E300-CP02-31;S2E300-AP02 -31

A2D200-AH18-01;S2D200-BH18-01;W2D200-CH18-01;S2D200-AH18-01;A2D200-AI18-01;S2D200-BI18-01
W2D200-CI18-01;S2D200-AI18-01;A2E200-AH38-01;S2E200-BH38-01;W2E200-CH38-01;S2E200-AH38-01

A2E200-AI38-01;S2E200-BI38-01;W2E200-CI38-01;S2E200-AI38-01;A4D200-AH14-01;S4D200-BH14-01
W4D200-CH14-01;S4D200-AH14-01;A4D200-AI14-01;S4D200-BI14-01;W4D200-CI14-01;S4D200-AI14-01
A4S200-AH04-01;S4S200-BH04-01;W4S200-CH04-01;S4S200-AH04-01;A4S200-AI04-01;S4S200-BI04-01
W4S200-CI04-01;S4S200-AI04-01;A2E250-AL06-01;S2E250-BL06-01;W2E250-CL06-01;S2E250-AL06-01

A2E250-AM06-01;S2E250-BM06-01;W2E250-CM06-01;S2E250-AM06-01;A4D250-AH22-01;S4D250-BH22-01
W4D250-CH22-01;S4D250-AH22-01;A4D250-AI22-01;S4D250-BI22-01;W4D250-CI22-01;S4D250-AI22-01

A4E250-AH02-01;S4E250-BH02-01;W4E250-CH02-01;S4E250-AH02-01;A4E250-AI02-01;S4E250-BI02-01
W4E250-CI02-01;S4E250-AI02-01;A4S250-AH02-01;S4S250-BH02-01;W4S250-CH02-01;S4S250-AH02-01
A4S250-AI02-01;S4S250-BI02-01;W4S250-CI02-01;S4S250-AI02-01;A2D250-AH02-01;S2D250-BH02-01
W2D250-CH02-01;S2D250-AH02-01;A2D250-AI02-01;S2D250-BI02-01;W2D250-CI02-01;S2D250-AI02-01

K3G250-RR17-H9 400VAC 1.15A Redundant Power Supply Module Germany Ebmpapst 0

FAQ

Q1. What about the lead time?

A: 3-5 days for Sample preparing ,8-10 working days for mass production.

Q2. Do you have any MOQ limit of Industrial Servo Drives?

A: Low MOQ, 1pc is available.

Q3. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.

Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

K3G250-RR17-H9 400VAC 1.15A Redundant Power Supply Module Germany Ebmpapst 1
