Name: 3051CFPDS010W1S0500D32AA1E5M5 Pressure Temperature Transmitter
Brand: Wisdomlong Technology CO.，LTD
SKU: 3051CFPDS010W1S0500D32AA1E5M5
Price: 1.00 USD
Availability: InStock

Home Products Pressure Temperature Transmitter

3051CFPDS010W1S0500D32AA1E5M5 Pressure Temperature Transmitter

Product Details:

Place of Origin:	Singapore
Brand Name:	ROSEMOUNT
Certification:	Does not supply
Model Number:	3051CFPDS010W1S0500D32AA1E5M5

Payment & Shipping Terms:

Minimum Order Quantity:	1 ea
Price:	Negotiate
Packaging Details:	In Box
Delivery Time:	8 WEEKS
Payment Terms:	T/T,PAYONEER
Supply Ability:	10EA，8weeks

Contact Now

Detailed Product Description

BRAND:	EMERSON ROSEMOUNT	MODEL:	3051CFPDS010W1S0500D32AA1E5M5
CATEGORY:	Integral Orifice Flow Meter	SUPPLY:	0 To 621,60 Mbar
Measurement Type:	Differential Pressure	Delivery Time:	8 Weeks
Highlight:	40mm Pressure Temperature Transmitter , 62160 mbar Pressure Temperature Transmitter , 3051CFP

3051CFPDS010W1S0500D32AA1E5M5 Integral Orifice Flow Meter 3051CFP Transmitter

Product Information Of : 3051CFPDS010W1S0500D32AA1E5M5

Brand	3051CFPDS010W1S0500D32AA1E5M5
SUPPLY	0 to 621,60 mbar
SIZE	No
Weight	Does not supply

Rosemount 3051CFP Integral Orifice Flow Meters enable highly accurate flow measurement in small line sizes. Integral Orifice Flow Meters use precision honed pipe section for increased accuracy and self-centering plate design to prevent alignment errors that magnify measurement inaccuracies in small line sizes.
■Up to 1.75 percent of flow rate accuracy.
■Available in ½- to 1½-in. (15 - 40 mm) line sizes.
■Fully assembled and leak tested for out-of-the-box installation.
■The Loop Integrity Diagnostic continuously monitors the electrical loop to detect changes that compromise the integrity of the transmitted 4-20 mA output signal (Option Code DA0).
■LOI with straightforward menus and built-in configuration buttons (option code M4).

More options :

SGDA-04BS

SGDA-04VP

SGDA-04VS

SGDA-05ADG+SGMG-05A2A

SGDA-08AP

SGDA-08APP

SGDA-08APPY128

SGDA-08AS

SGDA-08ASP

SGDA-08ASP SGDA-08AS

SGDA-08VP

SGD-A3AN

SGD-A5AN

SGD-A5BH

SGDA-A3AP

SGDA-A3BPM

SGDA-A3BS

SGDA-A3CPY14

MR-J2S-350B-EG117

MDS-B-SVJ2-01

MDS-B-SVJ2-03

MDS-B-SVJ2-04

MDS-B-SVJ2-06

MDS-B-SVJ2-10

MDS-B-SVJ2-20

MDS-B-SVJ2-07

MDS-D-SVJ3-01NA

MDS-D-SVJ3-02NA

MDS-D-SVJ3-07NA

MDS-D-SVJ3-10NA

MDS-D-SVJ3-20NA

Rosemount 3051CFP Integral Orifice Flow Meter Information:

Model	Product description
3051CFP	Integral orifice flow meter
Measurement type
D	Differential pressure	★
Body material
S	316 SST	★
Line size
005	½-in. (15 mm)	★
010	1-in. (25 mm)	★
015	1½-in. (40 mm)	★
Process connection
T1	NPT female body (not available with remote thermowell and RTD)	★
S1(1)	Socket weld body (not available with remote thermowell and RTD)	★
P1	Pipe ends: NPT threaded	★
P2	Pipe ends: beveled	★
D1	Pipe ends: Flanged, DIN PN16, slip-on	★
D2	Pipe ends: Flanged, DIN PN40, slip-on	★

D3	Pipe ends: Flanged, DIN PN100, slip-on	★
W1	Pipe ends: Flanged, RF, ANSI Class 150, weld-neck	★
W3	Pipe ends: Flanged, RF, ANSI Class 300, weld-neck	★
W6	Pipe ends: Flanged, RF, ANSI Class 600, weld-neck	★
A1	Pipe ends: Flanged, RF, ANSI Class 150, slip-on
A3	Pipe ends: Flanged, RF, ANSI Class 300, slip-on
A6	Pipe ends: Flanged, RF, ANSI Class 600, slip-on
R1	Pipe ends: Flanged, RTJ, ANSI Class 150, slip-on
R3	Pipe ends: Flanged, RTJ, ANSI Class 300, slip-on
R6	Pipe ends: Flanged, RTJ, ANSI Class 600, slip-on
Orifice plate material
S	316 SST	★
H	Alloy C-276
M	Alloy 400
Bore size option
0066	0.066-in. (1.68 mm) for ½-in. pipe	★
0109	0.109-in. (2.77 mm) for ½-in. pipe	★
0160	0.160-in. (4.06 mm) for ½-in. pipe	★
0196	0.196-in. (4.98 mm) for ½-in. pipe	★
0260	0.260-in. (6.60 mm) for ½-in. pipe	★
0340	0.340-in. (8.64 mm) for ½-in. pipe	★
0150	0.150-in. (3.81 mm) for 1-in. pipe	★
0250	0.250-in. (6.35 mm) for 1-in. pipe	★
0345	0.345-in. (8.76 mm) for 1-in. Pipe	★
0500	0.500-in. (12.70 mm) for 1-in. pipe	★
0630	0.630-in. (16.00 mm) for 1-in. pipe	★
0800	0.800-in. (20.32 mm) for 1-in. pipe	★
0295	0.295-in. (7.49 mm) for 1½-in. pipe	★
0376	0.376-in. (9.55 mm) for 1½-in. pipe	★
0512	0.512-in. (13.00 mm) for 1½-in. pipe	★
0748	0.748-in. (19.00 mm) for 1½-in. pipe	★
1022	1.022-in. (25.96 mm) for 1½-in. pipe	★
1184	1.184-in. (30.07 mm) for 1½-in. pipe	★
0010	0.010-in. (0.25 mm) for ½-in. pipe
0014	0.014-in. (0.36 mm) for ½-in. pipe
0020	0.020-in. (0.51 mm) for ½-in. pipe

0034	0.034-in. (0.86 mm) for ½-in. pipe
Transmitter connection platform
D3	Direct-mount, 3-valve manifold, SST		★
D5	Direct-mount, 5-valve manifold, SST		★
R3	Remote-mount, 3-valve manifold, SST		★
R5	Remote-mount, 5-valve manifold, SST		★
D4	Direct-mount, 3-valve manifold, alloy C-276
D6	Direct-mount, 5-valve manifold, alloy C-276
D7	Direct-mount, high temperature, 5-valve manifold, SST
R4	Remote-mount, 3-valve manifold, alloy C-276
R6	Remote-mount, 5-valve manifold, alloy C-276
Differential pressure ranges
1	0 to 25 in H₂O (0 to 62,16 mbar)		★
2	0 to 250 in H₂O (0 to 621,60 mbar)		★
3	0 to 1000 in H₂O (0 to 2,48 bar)		★
Transmitter output
A(2)	4–20 mA with digital signal based on HART^® Protocol		★
F	FOUNDATION™ Fieldbus Protocol		★
W(3)	PROFIBUS^® PA Protocol		★
X(4)	Wireless		★
M(5)	Low-power 1–5 Vdc with digital signal based on HART Protocol
Transmitter housing material		Conduit entry size
A	Aluminum	½–14 NPT	★
B	Aluminum	M20 x 1.5	★
E	Aluminum, ultra low copper	½–14 NPT
F	Aluminum, ultra low copper	M20 x 1.5
J	SST	½–14 NPT	★
K	SST	M20 x 1.5	★
P(6)	Engineered polymer	No conduit entries	★
D(7)	Aluminum	G½
M(7)	SST	G½
Transmitter performance class
1	up to ±1.8% flow rate accuracy, 8:1 flow turndown, 5-year stability		★
Wireless options (requires wireless output code X and engineered polymer housing code P)
Wireless transmit rate, operating frequency, and protocol
WA3	User configurable transmit rate, 2.4GHz WirelessHART		★

Antenna and SmartPower
WP5	Internal antenna, compatible with Green Power Module (I.S. Power Module sold separately)	★
Options (include with selected model number)
Extended product warranty
WR3	3-year limited warranty	★
WR5	5-year limited warranty	★
Transmitter body/bolt material
GT	High temperature (850 °F/454 °C)
Temperature sensor(8)
RT	Thermowell and RTD
Optional connection
G1	DIN 19213 transmitter connection	★
Pressure testing(9)
P1	Hydrostatic testing with certificate
Special cleaning
P2	Cleaning for special services
PA	Cleaning per ASTM G93 level D (section 11.4)
Material testing
V1	Dye penetrant exam
Material examination
V2	Radiographic examination
Flow calibration(10)
WD	Discharge coefficient verification
Special inspection
QC1	Visual and dimensional inspection with certificate	★
QC7	Inspection and performance certificate	★
Material traceability certification
Q8	Material traceability certification per EN 10204:2004 3.1	★
Code conformance(11)
J2	ANSI/ASME B31.1
J3	ANSI/ASME B31.3
J4	ANSI/ASME B31.8
Materials conformance(12)
J5	NACE MR-0175/ISO 15156
Country certification
J6	European Pressure Directive (PED)	★

J1	Canadian Registration
Transmitter calibration certification
Q4	Calibration Certificate for Transmitter	★
Quality certification for safety(13)
QS	Prior-use certificate of FMEDA data	★
QT	Safety certified to IEC 61508 with certificate of FMEDA	★
Product certifications
E8	ATEX Flameproof, Dust	★
I1(14)	ATEX Intrinsic Safety and Dust	★
IA	ATEX FISCO Intrinsic Safety; for FOUNDATION Fieldbus or PROFIBUS PA Protocols only	★
N1	ATEX Type n and Dust	★
K8	ATEX Flameproof, Intrinsic Safety, Type n, and Dust (combination of E8, I1, and N1)	★
E5	FM Explosion-proof, Dust Ignition-proof	★
I5(15)	FM Intrinsically Safe, Nonincendive	★
IE	FM FISCO Intrinsically Safe; for FOUNDATION Fieldbus or PROFIBUS PA Protocols only	★
K5	FM Explosion-proof, Dust Ignition-proof, Intrinsically Safe, and Division 2 (combination of E5 and I5)	★
C6	CSA Explosion-proof, Dust Ignition-proof, Intrinsically Safe, and Division 2	★
I6 (6)	CSA Intrinsically Safe	★
K6	CSA and ATEX Explosion-proof, Intrinsically Safe, and Division 2 (combination of C6, E8, and I1)	★
E7	IECEx Flameproof, Dust Ignition-proof	★
I7	IECEx Intrinsic Safety	★
N7	IECEx Type n	★
K7	IECEx Flameproof, Dust Ignition-proof, Intrinsic Safety, and Type n (combination of I7, N7, and E7)	★
E2	INMETRO Flameproof	★
I2	INMETRO Intrinsic Safety	★
IB	INMETRO FISCO intrinsically safe; for FOUNDATION Fieldbus or PROFIBUS PA Protocols only	★
K2	INMETRO Flameproof, Intrinsic Safety	★
E3	China Flameproof	★
I3	China Intrinsic Safety	★
KB	FM and CSA Explosion-proof, Dust Ignition-proof, Intrinsically Safe, and Division 2 (combination of K5 and C6)	★
KD	CSA, FM, and ATEX Explosion-proof, Intrinsically Safe (combination of K5, C6, I1, and E8)	★
Sensor fill fluid and O-ring options
L1(16)	Inert sensor fill fluid	★
L2	Graphite-filled (PTFE) O-ring	★
LA(16)	Inert sensor fill fluid and graphite-filled (PTFE) O-ring	★

Shipboard approvals(16)
SBS	American Bureau of Shipping	★
SLL(17)	Lloyds Register (LR)
Display and interface options
M4(18)	LCD display with LOI	★
M5	LCD display	★
Transient protection(16)(19)
T1	Transient terminal block	★
Plantweb^™ control functionality(20)
A01	FOUNDATION Fieldbus control function block suite	★
Plantweb diagnostic functionality
DA0(13)	Loop Integrity HART Diagnostic	★
D01(20)	FOUNDATION Fieldbus diagnostic suite	★
Low power output
C2	0.8–3.2 Vdc output with digital signal based on HART Protocol (available with output code M only)
Alarm levels(13)
C4(21)	NAMUR alarm and saturation levels, high alarm	★
CN(21)	NAMUR alarm and saturation levels, low alarm	★
CR	Custom alarm and saturation signal levels, high alarm	★
CS	Custom alarm and saturation signal levels, low alarm	★
CT	Rosemount standard low alarm	★
Ground screw(16) (22)
V5	External ground screw assembly	★
Configuration buttons
D4(13)	Analog zero and span	★
DZ(23)	Digital zero trim	★
Hart Revision configuration (requires HART Protocol output code A)(2)
HR5	Configured for HART Revision 5	★
HR7	Configured for HART Revision 7	★
Typical model number: 3051CFP D S 010 W1 S 0500 D3 2 A A 1 E5 M5

Good Service in WTL:
> We offer high quality, fast delivery, competitive price for Mitsubishi Servo Motor and Servo Drive.
> Please send your RFQ to get the latest price.
> Normally, we will ship the items in 1-2 weeks after receive the payment.
> We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways.
> We have a large stock and the prices are variable, so sometimes the prices we post are not accurate.

If needed, please contact us for specific prices.

OUR MAIN BRAND:

Tag:

Contact Person: Ms. Florence Zhang

Tel: 86-18318060200

Fax: Zhang hefei

Other Products

3051CFADL060DCHPS2T100032AA1 Pressure Temperature Transmitter Annubar Flow Meter Differential Pressure

BRAND: EMERSON ROSEMOUNT

MODEL: 3051CFADL060DCHPS2T100032AA1

CATEGORY: Annubar Flow Meter

SUPPLY: NOS

3051L2AA0D21AAF1 Rosemount 3051 Flow Meter Transmitter Rosemount Level Measurement

BRAND: EMERSON ROSEMOUNT

MODEL: 3051L2AA0D21AAF1

CATEGORY: Level Transmitter

SUPPLY: 4-20mA

5408A1SHA1E51R3ABCAB3M5DA1 Pressure Temperature Transmitter Level Transmitter

BRAND: EMERSON ROSEMOUNT

MODEL: 5408A1SHA1E51R3ABCAB3M5DA1

CATEGORY: Level Transmitter

SUPPLY: 4–20 mA

5301HA2P1N3BM00155AJI1M1HR7P1C1C4Q4Q8Q73Q76N2R7449QT Level Transmitter High Pressure

BRAND: EMERSON ROSEMOUNT

MODEL: 5301HA2P1N3BM00155AJI1M1HR7P1C1C4Q4Q8Q

CATEGORY: Pressure Temperature Transmitter

SUPPLY: 16-30VDC 25mA

DVC2000 Fisher FieldVue Pressure Temperature Transmitter Digital Valve Controller Transmitter

BRAND: FISHER

MODEL: DVC2000

CATEGORY: Digital Valve

SUPPLY: 30mA

5408F1SHA1E51R3ABCAB3M5DA1EF2QT 5408 Radar Level Transmitter SIS Level Transmitter

BRAND: EMERSON ROSEMOUNT

MODEL: 5408F1SHA1E51R3ABCAB3M5DA1EF2QT

CATEGORY: Level Transmitter

SUPPLY: 4–20 mA

3051CFPDS010W1S0500D32AA1E5M5 Pressure Temperature Transmitter

3051CFPDS010W1S0500D32AA1E5M5 Pressure Temperature Transmitter

40mm Pressure Temperature Transmitter

62160 mbar Pressure Temperature Transmitter

3051CFP

20mA Pressure Temperature Transmitter,

2088A1A22A1B4E8 Pressure Temperature Transmitter,

level transmitter rosemount 3051 20mA
