GE FANUC IC693MDL648 Discrete Input Module 0 To 60 VDC Input Voltage Range

GE FANUC IC693MDL648 TYPICAL SCAN RATE SERIES 90-30 PROCESSOR MODULE



Technical Specifications for IC693MDL648

Brand GE Fanuc
Series Series 90-30
Part Number IC693MDL648
Module Type Discrete Input
Power Type DC
Input Voltage Range 0 to 60 VDC

Input Current (mA) 4.2
Number of Points 16
Response Time (ms) 1 ms on/1 ms off
Trigger Voltage 34 to 60 Volts
Product Lifecycle Status* Discontinued/Obsolete



About IC693MDL648



The IC693MDL648 module is a discrete input module made for the programmable logic controllers or PLCs that are manufactured by the

GE Fanuc company. The PLC discrete input module is classified under Series 90-30 of the GE Fanuc PLCs. It is a 48 Volts DC rated positive

and negative logic input device with up to 16 input points. The IC693MDL648 module features an input voltage range 0 to 60 Volts DC while

the input current is rated as 4.2 milliamps. This 16-point PLC discrete input module features 34 to 60 Volts of trigger voltage while the connector

type is a terminal block connector with 20 screws that are included with the module. The IC693MDL648 module also features 80 milliamps of

current at 5 Volts DC or 125 milliamps of current at 24 Volts DC when it is isolated.







The IC693MDL648 module features a baseplate comprising 3 main parts. The 3 components on the baseplate include the circuit board that is

mounted to the metal backplate with a plastic cover, the I/O bus expansion cables, and the dedicated I/O communication bus. The

IC693MDL648 module's metal backplate features 4 holes that are used for mounting the baseplate and it also comes with the retainer slots

that mount the modules. Ideally, the GE Fanuc PLC controllers feature up to 5 prewired I/O bus expansion cables. The signals on the remote

baseplate backplane are optically coupled with an isolated DC-DC power supply converter, which is provided to serve as isolation for the

signals from the other backplanes. The IC693MDL648 module features the power bus that connects the power supply outputs to the modules

in the baseplate. Its I/O communication bus is installed with I/O modules over the bus. The bus connects to the I/O busses in the expansion

and remote racks through the I/O bus expansion connectors and the cables.
