Name: TC562 3BSC630049R1 Short Distance Modem ABB G1 Compliant
Brand: Wisdomlong Technology CO.，LTD
SKU: TC562 3BSC630049R1
Price: 1.00 USD
Availability: InStock

Home Products Redundant Power Supply Module

TC562 3BSC630049R1 Short Distance Modem ABB G1 Compliant

Product Details:

Place of Origin:	FI
Brand Name:	ABB
Certification:	Does not supply
Model Number:	TC562 3BSC630049R1

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiation
Packaging Details:	in box
Delivery Time:	3-5days
Payment Terms:	T/T, Western Union, PAYONEER
Supply Ability:	10

Contact Now

Detailed Product Description

Brand:	ABB	Channel Type:	DI
Weight:	0.3kg	Isolation:	Individually Galvanic Isolated Channels
Product Type:	I-O_Module	Product ID:	TC562 3BSC630049R1
RoHS Status:	Following EU Directive 2011/65/EU	Part Number:	TC562 3BSC630049R1

TC562 3BSC630049R1 Short Distance Modem ABB G1 Compliant

Additional Information

Medium Description:

Length < 10 km. Point-to-point up to 1 km at 19200 bps. G1 compliant. Power 24V d.c. To be used with CI531, CI532Vxx, CI534Vxx, CI853. Note! This part is exempted from the scope of 2011/65/EU (RoHS) as provided in Article 2(4)(c), (e), (f) and (j) therein (ref.: 3BSE088609 – EU DECLARATION OF CONFORMITY - ABB Advant Master Process Control System)

Product Type: Communication_Module

Ordering

HS Code:

851762-- Telephone sets, including telephones for cellular networks or for other wireless networks; other apparatus for the transmission or reception of voice, images or other data, including apparatus for communication in a wired or wireless network (such as a local or wide area network), other than transmission or reception apparatus of heading 84.43, 85.25, 85.27 or 85.28.- Other apparatus for transmission or reception of voice, images or other data, including apparatus for communication in a wired or wireless network (such as a local or wide area network) :-- Machines for the reception, conversion and transmission or regeneration of voice, images or other data, including switching and routing apparatus

Customs Tariff Number: 85176200

Dimensions

Product Net Depth / Length: 170 mm

Product Net Height: 230 mm

Product Net Width: 60 mm

Product Net Weight: 0.4 kg

Environmental

RoHS Status: Following EU Directive 2011/65/EU

WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)

Number of Batteries: 0

SCIP: No SVHC present Sweden (SE)

FAQ:

Q: What is the brand name of the product?
A: The brand name of the product is ABB.
Q: What is the model number of the product?
A: The model number of the product is TK212A 3BSC630197R1.
Q: Where is the product manufactured?
A: The product is manufactured in FI.
Q: What are the available payment terms?
A: The available payment terms are T/T, Western Union, and PAYONEER.
Q: What is the delivery time for the product?
A: The delivery time for the product is 3-5 days.
