ABB CD722F 3BDH000393R0001 Frequency Input Module

Product Details:

Place of Origin:	FI
Brand Name:	ABB
Certification:	Does not supply
Model Number:	CD722F 3BDH000393R0001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiation
Packaging Details:	in box
Delivery Time:	3-5days
Payment Terms:	T/T, Western Union, PAYONEER
Supply Ability:	10

Contact Now

Detailed Product Description

Brand:	ABB	Channel Type:	DI
Weight:	0.3kg	Isolation:	Individually Galvanic Isolated Channels
Product Type:	I-O_Module	Product ID:	CD722F 3BDH000393R0001
RoHS Status:	Following EU Directive 2011/65/EU	Part Number:	CD722F 3BDH000393R0001
Highlight:	3BDH000393R0001 Frequency Input Module , ABB Frequency Input Module , CD722F Frequency Input Module

ABB CD722F 3BDH000393R0001 Frequency Input Module

Long Description:

The frequency input module CD 722F has the following features: Two independent counting functions with up to 12 configurable modes (including incremental position encoder and frequency input up to 300 kHz). Two independent PWM (pulse-width modulator) or pulse outputs with push-pull driver. Dedicated inputs/outputs for specific counting functions (e.g. touch, set, reset). All unused inputs/outputs can be used with the specifications of standard inputs/outputs range. The inputs and outputs are electrically isolated from the other electronic circuitry of the module. There is no potential separation between the channels. This I/O module can be used as PROFIBUS remote I/O.

Additional Information

Medium Description:

For PROFIBUS slave only. A Frequency Input Module for connecting 2 encoder inputs, 2 PWM outputs, 2 digital inputs and 8 configurable digital inputs/outputs. 2 Counter Inputs: 5/24 VDC, 1 Vpp sinus, fmax 300 kHz 2 DO: 24 VDC/0,1 A, pulse width PWM 2 DI: 24 VDC 8 DI/DO: 24 VDC/0,5 A 1/2-wire, 24 VDC 100 W Use with TU 715F / TU 716F

Product Type: I-O_Module

Ordering

HS Code:

853890-- Parts suitable for use solely or principally with the apparatus of heading 85.35, 85.36 or 85.37.- Other

Customs Tariff Number: 85389099

Dimensions

Product Net Depth / Length: 54 mm

Product Net Height: 76 mm

Product Net Width: 67.5 mm

Product Net Weight: 0.125 kg

Technical

Channel Type: VX

Number of Input Channels: 7

Number of Output Channels: 7

Environmental

RoHS Status: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)

Number of Batteries: 0

FAQ:

Q: What is the brand name of the product?
A: The brand name of the product is ABB.
Q: What is the model number of the product?
A: The model number of the product is CD722F 3BDH000393R0001.
Q: Where is the product manufactured?
A: The product is manufactured in FI.
Q: What are the available payment terms?
A: The available payment terms are T/T, Western Union, and PAYONEER.
Q: What is the delivery time for the product?
A: The delivery time for the product is 3-5 days.
