ABB DA701F 3BDH000371R0005 DA701F Digital/Analog Module

The analog input/output module DA 701F offers quite more flexibility, as it combines analog input and output as well as digital input and output channels in one module with 30 channels.
Four of these channels can be individually configured as analog inputs, which can again sense voltage, current, or temperatures (RTD). Two channels can be configured as analog voltage outputs (-10 V to +10 V), or analog current outputs (0 … 20 mA or 4 … 20 mA). 16 channels are digital inputs (24 V DC) and the remaining 8 channels are usable for digital output signals (24 V DC).
The inputs and outputs are electrically isolated from the other electronic circuitry of the module. There is no potential separation between the channels.
This module is usable for PROFIBUS remote I/O and AC 700F / AC 900F direct I/O.
