AB 1606-XL120E-3 Power boost up to 144 W 3 phase wide range input High overload current

Product Details:

Place of Origin:	USA
Brand Name:	AB
Model Number:	1606-XL120E-3

Payment & Shipping Terms:

Price:	negotiation
Packaging Details:	New in original boxRockwell Automation
Delivery Time:	5-8 work daysRockwell Automation
Payment Terms:	T/T
Supply Ability:	1

Contact Now

Detailed Product Description

Condition:	New	Nominal Output Voltage:	120 / 240 VAC
Product Type:	Input Module	Warranty:	1 Year
Memory Requirement:	4 Bytes	Rated Voltage:	1Watts
Output Voltage Range:	-20 To +20 MA (or) -10 To +10V Dc	Communication Rate:	5.1 MA At 24V Dc

AB 1606-XL120E-3 Power boost up to 144 W 3 phase wide range input High overload current

About 1606-XL120E-3 :

Output:
24...28V DC, adjustable by (covered) front panel potentiometer, preset: 24.5V ± 0.5% Adjusting range guaranteed

Output noise suppression:
Radiated EMI values below EN50081-1, even when using long, unscreened output cables

Ambient temperature range Tamb:
Operation: -10°C...+70°C (>60°C: Derating) Storage: -25°C...+85°C

Design advantages:
• All connection blocks are easy to reach as mounted at the front panel.
• Input and output are strictly apart from each other and so cannot be mixed up (Input below, output above). Wire Size Input/Output:
• Stranded 20...10 AWG (0.5...4 mm²), Solid 20...10 AWG (0.5...6 mm²) Tightening Torque: 7 lbs in (0.8 Nm) recommended

POWER SUPPLY
1606-XL SERIES
INPUT VOLTAGE - 380-480 V AC
RATED OUTPUT - 120 W
24-28 V DC OUTPUT
THREE PHASE

More information:

Height	124 mm
Depth	102 mm
Direct mounting possible	No
Width	32 mm
Degree of protection (IP)	IP20
Type of electric connection	Screw connection
Shock	30 G, 6ms 20 G, 11ms
MTBF	867 kh (40 °C, SN29500)
Wall mounting possible	Yes
Vibration	2 G

Another module:
SLC 500 Digital I/O Modules Input Catalog Numbers
1746-IA4, 1746-IA8, 1746-IA16, 1746-IB8, 1746-IB16, 1746-IC16, 1746-IG16, 1746-IH16, 1746-IM4, 1746-IM8, 1746-IM16, 1746-IN16, 1746-ITB16, 1746-ITV16, 1746-IV8, 1746-IV16

Output Catalog Numbers
1746-OA8, 1746-OA16, 1746-OAP12, 1746-OB8, 1746-OB6EI, 1746-OB16, 1746-OB16E, 1746-OBP8, 1746-OBP16, 1746-OG16, 1746-OV8, 1746-OV16, 1746-OVP16, 1746-OW4, 1746-OW8, 1746-OW16, 1746-OX8

Combination Input/Output Catalog Numbers
1746-IO4, 1746-IO8, 1746-IO12, 1746-IO12DC
