AB 1606-XLE120E Essential Power Supply 24-28V DC Output Voltage Single Phase

Product Details:

Place of Origin:	USA
Brand Name:	AB
Model Number:	1606-XLE120E

Payment & Shipping Terms:

Price:	negotiation
Packaging Details:	New in original boxRockwell Automation
Delivery Time:	5-8 work daysRockwell Automation
Payment Terms:	T/T
Supply Ability:	1

Contact Now

Detailed Product Description

Condition:	New	Nominal Output Voltage:	120 / 240 VAC
Product Type:	Input Module	Warranty:	1 Year
Memory Requirement:	0.541kg	Rated Voltage:	1Watts
Output Voltage Range:	-20 To +20 MA (or) -10 To +10V Dc	Communication Rate:	5.1 MA At 24V Dc

AB 1606-XLE120E Essential Power Supply 24-28V DC Output Voltage Single Phase

About 1606-XL120E :

Output:
1606-XLE120E AC/DC Essential Power Supply 24-28V DC Output Voltage, 5A, 120W, Single Phase, 120/230V AC Input Voltage, Standard Module, DINRail mount, Series A

Output noise suppression:
Radiated EMI values below EN50081-1, even when using long, unscreened output cables

Ambient temperature range Tamb:
Operation: -10°C...+70°C (>60°C: Derating) Storage: -25°C...+85°C

Instructions:
a) Use appropriate copper cables that are designed for an operating temperature of: 60°C for ambient up to 45°C and 75°C for ambient up to 60°C minimum.

b) Follow national installation codes and installation regulations!

c) Ensure that all strands of a stranded wire enter the terminal connection!

d) Up to two stranded wires with the same cross section are permitted in one connection point (except PE wire).

e) Do not use the unit without PE connection.

POWER SUPPLY
1606-XLE SERIES
ESSENTIAL POWER
INPUT VOLTAGE - 100-240 V AC
RATED OUTPUT - 120 W
24-28 V DC OUTPUT

1606-XLE120E & 1606-XLE120EC 24V, 5A; Single Phase Input
Above an average output current of 2.7A, the harmonic current standard EN61000-3-2 is not fulfilled.
Please note:
A power supply has to comply with EN 61000-3-2 (Standard for harmonic input current) when:
1) the end-device is used within the European Union and
2) the end-device is connected to a public mains supply with a nominal voltage ≥ 220Vac and
3) the power supply is:
- fitted in an end-device with an average input power in excess of 75W or
- fitted in an end-device with a continuous input power in excess of 75W or
- part of a lighting system.

More information:

Nominal value output voltage 1	24 V
Secondary voltage adjustable	Yes
Max. output current 1	5 A
Nominal value output current 1	5 A
Power output	120 W
Voltage type of supply voltage	AC/DC
1st secondary output voltage	24 V
Rated supply voltage at AC 50 Hz	100 V
Rated supply voltage at AC 60 Hz	100 V
Rated supply voltage at DC	110 V
Power reserves	20 %
Derating	3 W/°C
DC OK relay contact	Yes
Input inrush current limiter	Active
Adjustment range	24 V
Power factor	0.91 typical
Operational range	90…132V AC
Rated output current	5 A, 24V
External input fuse, min	B-6 A or C-6 A
Power losses	7.3 W typical
Sub group	Essential line
Hold-up time	>80 ms @ 120V
Efficiency	94.3% typical
Input inrush current	4 A/3 A
Special family function	Dynamic 120% power boost under 45C Degree
Rated input current	2.6 A, 100V AC
Output voltage stabilized	Yes
Rail mounting possible	Yes
Stabilized	Yes

Another module:
SLC 500 Digital I/O Modules Input Catalog Numbers
1746-IA4, 1746-IA8, 1746-IA16, 1746-IB8, 1746-IB16, 1746-IC16, 1746-IG16, 1746-IH16, 1746-IM4, 1746-IM8, 1746-IM16, 1746-IN16, 1746-ITB16, 1746-ITV16, 1746-IV8, 1746-IV16

Output Catalog Numbers
1746-OA8, 1746-OA16, 1746-OAP12, 1746-OB8, 1746-OB6EI, 1746-OB16, 1746-OB16E, 1746-OBP8, 1746-OBP16, 1746-OG16, 1746-OV8, 1746-OV16, 1746-OVP16, 1746-OW4, 1746-OW8, 1746-OW16, 1746-OX8

Combination Input/Output Catalog Numbers
1746-IO4, 1746-IO8, 1746-IO12, 1746-IO12DC
