GE FANUC IC693CHS391 SERIES 90-30 PROGRAMMABLE LOGIC CONTROLLER (PLC)

GE FANUC IC693CHS391 SERIES 90-30 PROGRAMMABLE LOGIC CONTROLLER (PLC)

Technical Specifications for IC693CHS391

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc
Part Number IC693CHS391
Series Series 90-30
Description Expansion baseplate
Product Description Modular CPU baseplate
Current 420 milliAmperes
No. of slots Ten (10) slots
Voltage 5 Volts DC
No. of CPU slots One (1)
Connector 25-Pin female
No. of I/O slots Nine (9)
No. of Power supply slots One (1)

PLC Connection Supported
Expansion baseplate slot One (1)
Computer Connection Supported with a PCI Card
Slot assignment CPU / Specialty module: Slot 1 I/O module / Option modules: Slot 2-10

Unnumbered slot: Power supply module Expansion cable: Expansion cable
Standard Operation Not Supported
Default rack address Rack number 0
Product Lifecycle Status* Discontinued/Obsolete
Number of permitted CPU baseplate per system:
One (1) Mounting
Panel Mounting Current load:
250 mA Bus voltage:+5VDC







About IC693CHS391

The IC693CHS391 is a Modular CPU baseplate. This baseplate is part of the Series 90-30 that is manufactured by GE Fanuc.

This device houses the connection ports, allowing modular CPUs, I/O modules and Power supply module installation. It has a

total of Ten (10) slots with One (1) slot assigned to the CPU and Nine (9) slots for the I/O modules. Power supply slot is not

included in the slot count as well as the bus expansion port.

Since this is a modular CPU slot, it is by default assigned with a node address of 0 which can be modified through the

programming software. Only One (1) modular CPU slot is supported by a system. Other slots in the system could be expansion

or remote I/O baseplates.

Power supply is installed to the left most slot which is not included in the counting of slots, allowing more I/O to be supported

by this baseplate. CPU is installed only the Slot 1 as this slot is especially sized for CPU connection or special option module

such as the FIP Bus Remote I/O scanner. Slot number 2 and higher are particularly sized for I/O or option modules. Expansion

or remote I/O basesplate are connected through the expansion port at the right most portion of the baseplate. Depending on

the CPU hosted by the IC693CHS391, up to Four (4) or Seven (7) expansion baseplates are supported by the IC693CHS391

Modular CPU baseplate. This baseplate supports panel mounting only, fastened by screws and washers through the mounting

holes provided.

The IC693CHS391 baseplate is a GE Fanuc manufactured expansion baseplate equipped with ten slots. It runs with a current

rating of 420 mA and it has a voltage rating of 5 Volts DC. It is equipped with a DIP switch. The expansion base plate is

connected to the Series 90-30 PLCs along with other modules. A power supply module is plugged into the left slot the baseplate.

The IC693CHS391 baseplate is modular in size and it has an open enclosure. It can be easily installed and replaced or changed

to a different type if an extra feature is required. A power supply port is present on the left side of the plate along with

connectivity slots for CPU and non-CPU slots. It also has a 25-pin female connector present on the right hand side for

connecting expansion and remote baseplates.

To be connected with a remote baseplate, the IC693CHS391 expansion baseplate requires a cable with a length of less than 700

feet. The baseplate cannot be used as a single entity. It can either be connected to a PLC device or a personal computer that is

using a PCI card. It can connect to up to 7 CPUs at a time depending on the model of the CPUs that are used. The IC693CHS391

baseplate can be mounted either vertically or horizontally depending on the layout of the PLC or the CPU. The environmental

temperature should always be in the specified range. The plate should be kept away from water splashes and sources of dust,

dirt, and harmful chemicals. The IC693CHS391 baseplate is certified by several global environmental and industrial standards.
