GE FANUC IC693CMM301 SERIES 90-30 PROGRAMMABLE LOGIC CONTROLLER (PLC)

GE FANUC IC693CMM301 SERIES 90-30 PROGRAMMABLE LOGIC CONTROLLER (PLC)

Technical Specifications for IC693CMM301

Manufacturer GE Fanuc
Series Series 90-30
Part Number IC693CMM301
Product Type Genius Communications Module
Compatible Host PLCs Series 90-30 PLCs
Data Type Global Data

Maximum Data Rate 256 Bits (32 Bytes)
LEDs 2 (OK LED and COM LED)
Operating Temperature 32 to 140 degrees Fahrenheit
Storage Temperature -13 to 158 degrees Fahrenheit
Product Lifecycle Status* Discontinued/Obsolete

About IC693CMM301

The GE Fanuc IC693CMM301 module is a Series 90-30 Genius Communications Module. This module is made to communicate

automatically. It makes “global data” communications possible between a GE Fanuc Series 90-30 PLC and as many as 7

additional devices with a Genius bus. Global data communications are communications that involve data which is transmitted

repeatedly and automatically and which can be received by multiple devices with a shared database. Some of the devices that

the IC693CMM301 Genius Communications Module can provide global data to include GE Series 90-30 PLCs, GE Series 90-70

PLCs, a computer that is used for programming and configuration applications, and another computer with a PCIM card that is

used for data monitoring applications



The GE Fanuc IC693CMM301 Genius Communications Module can exchange a maximum of 32 bytes or 256 bits of data in total.

It is easy to connect the IC693CMM301 Genius Communications Module to the backplate of the PLC that hosts it. This module

has no jumpers or DIP switches, so it must be configured with a handheld programmer or with the proper system programming

software. There are 2 LEDs on the IC693CMM301 Genius Communications Module. The OK LED means that the module has

completed and passed its powerup test and that it is operating properly. The COM LED means that the module has been

initialized by a Series 90-30 GE PLC and that the module is receiving bus communications. The COM LED will stay on after a

successful startup and throughout operation unless there is a significantly high number errors, which will cause the COM LED to

blink.
