Emerson KJ3222X1-BA1 AI 8-Channel 4-20 mA HART Series 2 Redundant Card
Hazardous Atmosphere
Ex nA IIC Gc (4-Wire)
Ex nA [nL] IIC Gc (2-Wire)
Ex nA [ic] IIC Gc (2-Wire)
FM13ATEX0034U IECEx FMG 13.0015U
Power Specifications
LocalBus power rating : 12 VDC at 150 mA
Bussed field power rating : 24 VDC at 300 mA
Field circuit rating :24 VDC at 30 mA
Environmental Specifications
Ambient Temperature : -40 to 70o C
Shock :10g ½ Sinewave for 11 msec
Vibration :1mm Peak to Peak from 5 to 16Hz; 0.5g from 16 to 150Hz
Airborne Contaminants: ISA-S71.04 –1985 Airborne Contaminants Class G3
Relative Humidity :5 to 95% Non-Condensing IP 20 Rating
Terminal block key position: A1
Note: Refer to the product label for serial number and location and date of manufacture. Refer also to the wiring diagram on the left side of the card.
Removal and Insertion
Field power supplied to this device, either at the field terminal or as bussed field power through the carrier, must be removed before removing or connecting the device.
This unit may be removed or inserted while system power is energized under the following conditions: (Note Only one unit at a time may be removed with system power energized.)
• When used with KJ1501X1-BC1 System Dual DC/DC Power Supply operating on 24 VDC or 12 VDC input power. The primary circuit wiring inductance for input power must be less than 23 uH, or a certified supply with an open circuit voltage, Ui of 12.6 VDC and an Lo of less than 23 uH (including wire inductance).
An I/O loop assessment must be completed on all energy-limited nodes. A terminal block fuse may NOT be removed with field power energized for non-sparking circuits.
Quick Details:
- Condition: New
- Type: 8 Point Analog HART Input Module
- Make: Fisher Rosemount Emerson
- Series: DeltaV
- Model: KJ3222X1-BA1
- Part: 12P2532Xxxx
- Packaging: Original, Sealed
- Weight: 1.0kg
Specifications:
| Ports: |
2 |
| Isolation: |
Each AS-i port is optically isolated from each other and the system and factory tested to 1500 VDC |
| Operating temperature: |
-25 to 70 °C (-13 to 158 °F) |
| Storage Temperature: |
-40 to 85 °C (-40 to 185 °F) |
| Airborne contaminants: |
ISA-S71.04-1985 Airborne Contaminants Class G3 Conformal coating |
| Shock: |
10 g½ -sine wave for 11 ms |
| Vibration: |
1 mm peak-to-peak from 5 to 16 Hz;0.5 g from 16 to 150 Hz |
Introduction:
DeltaV™ M-series AS-I Interface Card
The DeltaV™ M-series actuator sensor interface (AS-i) is a field-proven interface for discrete actuators
and sensors. The interface uses an automatic addressing system via the bus connection to provide each
field device a specific tag name that identifies the device for configuration and diagnostic purposes. The
DeltaV system auto-senses AS-i devices and provides smooth activation of new devices. It is easy to
install, reliable and simple to use.
Buses and the DeltaV™ System
Features:
- Offers freedom to choose appropriate bus for application
- Supports standard device-level busses
- Reduces wiring costs
- Features native controller level interface
- Enables mix-and-match bus technologies to meet application requirements
