Name: TU805K01 3BSE035990R1 Compct MTU Module Base Redundant Power Supply Module
Brand: Wisdomlong Technology CO.，LTD
SKU: TU805K01 3BSE035990R1
Price: 1.00 USD
Availability: InStock

Home Products Redundant Power Supply Module

TU805K01 3BSE035990R1 Compct MTU Module Base Redundant Power Supply Module

Product Details:

Place of Origin:	FI
Brand Name:	ABB
Certification:	Does not supply
Model Number:	TU805K01 3BSE035990R1

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiation
Packaging Details:	in box
Delivery Time:	3-5days
Payment Terms:	T/T, Western Union, PAYONEER
Supply Ability:	10

Contact Now

Detailed Product Description

Brand:	ABB	Channel Type:	DI
Weight:	0.3kg	Isolation:	Individually Galvanic Isolated Channels
Product Type:	I-O_Module	Product ID:	TU805K01 3BSE035990R1
RoHS Status:	Following EU Directive 2011/65/EU	Part Number:	TU805K01 3BSE035990R1

TU805K01 3BSE035990R1 Compct MTU Module Base Redundant Power Supply Module

Description of TU805K01 3BSE035990R1

The TU805K01 is a kit consisting of 10 pcs TU805. TU805 is a 16-channel 50 V terminal unit for the S800 I/O modules DI801 and DO801. The Terminal Unit is a passive unit for the distribution of external process power.

General info

Article number	3BSE035990R1
Connection	Terminal block
Channels	16
Voltage	50 V
Use with I/O	DI801, DO801
Process connections	2 x 2 Process power terminals 2 x 16 Process power distribution terminals

Detailed data of TU805K01 3BSE035990R1

Maximum current per I/O channel	1 A
Acceptable wire sizes	Solid: 0.2 - 1.5 mm² Stranded: 0.2 - 1.5 mm², 24- 16 AWG
Dielectric test voltage	500 V a.c.

Environment and certification

CE mark	Yes
Electrical safety	EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201
Hazardous Location	C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2
Marine certification	DNV-GL
Temperature, Operating	0 to +55 °C (+32 to +131 °F), approvals are issued for +5 to +55 °C
Temperature, Storage	-40 to + 70 °C (-40 to +158 °F)
Pollution degree	Degree 2, IEC 60664-1
Corrosion protection	ISA-S71.04: G3
Relative humidity	5 to 95 %, non-condensing
Max ambient temperature	55 °C (131 °F)
Protection class	IP20 according to IEC 60529
Mechanical operating conditions	IEC/EN 61131-2
EMC	EN 61000-6-4, EN 61000-6-2
Overvoltage categories	IEC/EN 60664-1, EN 50178
Equipment class	Class I according to IEC 61140; (earth protected)
RoHS compliance	EN 50581:2012
WEEE compliance	DIRECTIVE/2012/19/EU

Dimensions of TU805K01 3BSE035990R1

Width	86.1 mm
Depth	40.5 mm
Height	40.5 mm
Weight	0.3 kg

Features and benefits

Enables 2- and 3-wire connections of process signals.
Direct mounting on the I/O module.
Requires no extra space.

FAQ:

Q: What is the brand name of the product?
A: The brand name of the product is ABB.
Q: What is the model number of the product?
A: The model number of the product is TU805K01 3BSE035990R1.
Q: Where is the product manufactured?
A: The product is manufactured in FI.
Q: What are the available payment terms?
A: The available payment terms are T/T, Western Union, and PAYONEER.
Q: What is the delivery time for the product?
A: The delivery time for the product is 3-5 days.
